IPA60R180P7 CoolMOS™ Power MOSFET with 600V Drain-Source Voltage 18A Continuous Drain Current and 145mOhms Drain-Source Resistance

IPA60R180P7 CoolMOS™ Power MOSFET with 600V Drain-Source Voltage 18A Continuous Drain Current and 145mOhms Drain-Source Resistance
IPA60R180P7 CoolMOS™ Power MOSFET with 600V Drain-Source Voltage 18A Continuous Drain Current and 145mOhms Drain-Source Resistance IPA60R180P7 CoolMOS™ Power MOSFET with 600V Drain-Source Voltage 18A Continuous Drain Current and 145mOhms Drain-Source Resistance

Large Image :  IPA60R180P7 CoolMOS™ Power MOSFET with 600V Drain-Source Voltage 18A Continuous Drain Current and 145mOhms Drain-Source Resistance

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: IPA60R180P7
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: TO-220-3
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

IPA60R180P7 CoolMOS™ Power MOSFET with 600V Drain-Source Voltage 18A Continuous Drain Current and 145mOhms Drain-Source Resistance

Description
Part Number: IPA60R180P7 Transistor Polarity:: N-Channel
Number Of Channels:: 1 Channel Vds - Drain-Source Breakdown Voltage:: 600 V
Id - Continuous Drain Current:: 18 A Rds On - Drain-Source Resistance:: 145 MOhms
Highlight:

600V Drain-Source Voltage Power MOSFET

,

18A Continuous Drain Current Integrated Circuit Chip

,

145mOhms Drain-Source Resistance CoolMOS™ Transistor

IPA60R180P7 Integrated Circuit Chip CoolMOS™ N-Channel 600 V Power MOSFET Transistors
The IPA60R180P7 600V CoolMOS™ P7 superjunction MOSFET is the successor to the 600V CoolMOS™ P6 series. It continues to balance the need for high efficiency against ease-of-use in the design process. The best-in-class RonxA and inherently low gate charge (QG) of the CoolMOS™ 7th generation platform ensure high efficiency performance.
Technical Specifications
Parameter Value
FET Type N-Channel
Technology MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss) 600 V
Current - Continuous Drain (Id) @ 25°C 18A (Tc)
Drive Voltage (Max Rds On, Min Rds On) 10V
Rds On (Max) @ Id, Vgs 180mOhm @ 5.6A, 10V
Vgs(th) (Max) @ Id 4V @ 280µA
Gate Charge (Qg) (Max) @ Vgs 25 nC @ 10 V
Vgs (Max) ±20V
Input Capacitance (Ciss) (Max) @ Vds 1081 pF @ 400 V
Power Dissipation (Max) 26W (Tc)
Operating Temperature -40°C ~ 150°C (TJ)
Key Features
  • CoolMOS™ 7 series technology
  • Low gate charge design
  • Low stored energy in COSS
  • Integrated gate resistor
  • Field-proven CoolMOS™ quality
  • CoolMOS™ platform since 1998
Performance Benefits
  • Enhanced control capabilities
  • High efficiency in hard switching applications
  • Higher power density
  • Versatile for hard & resonant topologies
  • Fully insulated package design
Application Areas
  • Power adapters and chargers
  • Cordless power tools and outdoor power equipment
  • LED lighting system design
  • Edge computing systems
