STK551U392A-E Automotive IGBT Modules High Integrated 600V 15A Half Bridge Intelligent Power Module

Large Image : STK551U392A-E Automotive IGBT Modules High Integrated 600V 15A Half Bridge Intelligent Power Module

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	STK551U392A-E

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	SIP-29
Delivery Time:	5-8 work days
Payment Terms:	T/T, L/C, Western Union

Contact Now

STK551U392A-E Automotive IGBT Modules High Integrated 600V 15A Half Bridge Intelligent Power Module

Description

Part Number:	STK551U392A-E	Collector- Emitter Voltage VCEO Max::	600 V
Maximum Operating Temperature::	+ 100 C	Minimum Operating Temperature::	- 40 C
Pd - Power Dissipation::	35 W	Unit Weight::	30 G
Highlight:	600V 15A automotive IGBT module , half bridge intelligent power module , high integrated automotive IGBT

STK551U392A-E Automotive IGBT Modules

High Integrated 600V 15A Half Bridge Intelligent Power Module

Product Overview

The STK551U392A-E Intelligent Power Module (IPM) is a highly integrated device containing all High Voltage (HV) control from HV-DC to 3-phase outputs in a single small SIP module. The output stage utilizes IGBT/FRD technology and implements Under Voltage Protection (UVP) and Over Current Protection (OCP). Internal Boost diodes are provided for high side gate boost drive.

Technical Specifications

Output Configuration	Half Bridge (3)
Applications	AC Motors
Interface	Logic
Load Type	Inductive
Technology	IGBT
Current - Output / Channel	15A
Current - Peak Output	30A
Voltage - Supply	12.5V ~ 17.5V
Voltage - Load	450V (Max)
Operating Temperature	-40°C ~ 150°C (TJ)
Features	Bootstrap Circuit, Latch Function, Status Flag
Fault Protection	Current Limiting, Shoot-Through, UVLO

Key Features

Over-current Protection Circuit
Under-voltage lockout for all channels
Upper / lower ON prevention circuit
Thermistor for case temperature monitor

Applications

3-phase Motor Control Systems
