RFCM3327 Integrated Circuit Chip 45MHz To 1218MHz GaAs/GaN Power Doubler Amplifier Module

RFCM3327 Integrated Circuit Chip 45MHz To 1218MHz GaAs/GaN Power Doubler Amplifier Module​

Product Description Of RFCM3327

RFCM3327 is a Power Doubler amplifier SMD Module. The part employs GaAs pHEMT die and GaN HEMT die, has high output capability, and is operated from 45 MHz to 1218 MHz. It provides excellent linearity and superior return loss performance with low noise and optimal reliability. DC current of the device can be externally adjusted for optimum distortion performance versus power consumption over a wide range of output level.

Specification Of RFCM3327

Features Of RFCM3327

Excellent linearity
Superior return loss performance
Extremely low distortion
Optimal reliability
Low noise
Unconditionally stable under all terminations
Extremely high output capability
22.5 dB Min. Gain at 1218 MHz
480 mA Max. at 24 VDC
Temperature sensing feature

Applications Of RFCM3327

45 MHz to 1218 MHz CATV Amplifier Systems

Other Electronic Components In Stock

FAQ
Q. Are your products original?
A: Yes, all products are original, new original import is our purpose.
Q:Which Certificates do you have?
A:We are ISO 9001:2015 Certified Company and member of ERAI.
Q:Can you support small quantity order or sample?Is the sample free?
A:Yes,we support sample order and small order.Sample cost is different according to your order or project.
Q:How to ship my order? Is it safe?
A:We use express to ship,such as DHL,Fedex,UPS,TNT,EMS.We can also use your suggested forwarder.Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
Q:What about the lead time?
A:We can ship stock parts within 5 working days.If without stock,we will confirm lead time for you based on your order quantity.
