MPL3115A2R1 Sensor IC 20kPa To 110kPa Absolute Digital Pressure Sensor

MPL3115A2R1 is a compact piezoresistive absolute pressure sensor with an I²C interface. The sensor features a wide operating range of 20 kPa to 110 kPa, covering all surface elevations on Earth.

• Calibrated range: 50 kPa to 110 kPa absolute pressure
• Operating range: 20 kPa to 110 kPa absolute pressure
• I²C digital output interface (up to 400 kHz)
• Fully compensated internally
• Programmable Interrupts
• 1.95 V to 3.6 V Supply Voltage, internally regulated
• 1.6 V to 3.6 V Digital Interface Supply Voltage
• Operating temperature from -40 °C to +85 °C
• 5 mm x 3 mm x 1.1 mm LGA package (1.25 mm lead pitch)
• MSL 1 compliant
• Direct Reading for Pressure, Altitude, and Temperature
• Autonomous Data Acquisition
• Embedded 32-Sample FIFO
• Data logging up to 12 days using the FIFO
• 1 second to 9 hour data acquisition rate

• Consumer Electronics: Smartphone
• Industrial: Continuous Glucose Monitoring (CGM)
• Wearables: Smart Watch and Wristband
• Medical: Vital Signs Monitors

A: Yes, all products are original, new original import is our purpose.

A: We are ISO 9001:2015 Certified Company and member of ERAI.

A: Yes, we support sample order and small order. Sample cost is different according to your order or project.

A: We use express to ship, such as DHL, Fedex, UPS, TNT, EMS. We can also use your suggested forwarder. Products will be in good packing and ensure the safety and we are responsible to product damage to your order.

A: We can ship stock parts within 5 working days. If without stock, we will confirm lead time for you based on your order quantity.
