TLE8201R Integrated Circuit Chip Automotive Door Module Power IC PG-DSO-36

Large Image : TLE8201R Integrated Circuit Chip Automotive Door Module Power IC PG-DSO-36

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	TLE8201R

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	PG-DSO-36
Delivery Time:	5-8 work days
Payment Terms:	T/T, L/C, Western Union

Contact Now

TLE8201R Integrated Circuit Chip Automotive Door Module Power IC PG-DSO-36

Description

Part Number:	TLE8201R	Operating Supply Current:	3 UA
Interface:	SPI	Voltage - Supply:	4.75V ~ 5.5V
Voltage - Load:	5V ~ 40V	Operating Temperature:	-40°C ~ 150°C (TJ)

TLE8201R Integrated Circuit Chip Automotive Door Module Power IC PG-DSO-36

TLE8201R Integrated Circuit Chip Automotive Door Module Power IC PG-DSO-36

Product Description

TLE8201R is an Application Specific Standard Product for automotive door-module applications. It includes all the power stages necessary to drive the loads in a typical front door application, including central lock, deadlock or mirror fold, mirror position, mirror defrost and 5W or 10W lamps for turn signal, courtesy/warning or control panel illumination. It is designed as a monolithic circuit in Infineon's mixed technology SPT which combines bipolar and CMOS control circuitry with DMOS power devices.

Specifications

Series	SPT®
Motor Type - AC, DC	Brushed DC
Function	Driver - Fully Integrated, Control and Power Stage
Output Configuration	Half Bridge (6), High Side (5)
Interface	SPI
Technology	DMOS
Voltage - Supply	4.75V ~ 5.5V
Voltage - Load	5V ~ 40V
Operating Temperature	-40°C ~ 150°C (TJ)
Mounting Type	Surface Mount
Package / Case	36-BSSOP (0.433", 11.00mm Width) Exposed Pad
Supplier Device Package	PG-DSO-36-27

Key Features

Full bridge (150mΩ) for main doorlock motor
Two half-bridges (400mΩ) for deadbolt and mirror position motor or mirror fold motor
Two half-bridges (800mΩ) for mirror position
High-side switch (100mΩ) for mirror defrost
Four high-side switches (500mΩ) for 5W and 10W lamps
Current sense analog output with multiplex
All outputs with short circuit protection and diagnosis
Over-temperature protection with warning
Open load diagnosis for all outputs
Charge pump-Output for n-channel MOS-FET reverse-polarity protection
Very low current consumption in sleep mode
Standard 16-bit SPI for control and diagnosis
Over-and Undervoltage Lockout
Power-SO package with full-size heatslug for excellent low thermal resistance
