SY89835UMG-TR Integrated Circuit Chip Ultra-Precision Differential 1:2 LVDS Fanout Buffer With Internal Termination And Fail Safe Input

SY89835UMG-TR is a 2.5V, high-speed 2GHz differential Low Voltage Differential Swing (LVDS) 1:2 fanout buffer optimized for ultra-low skew applications. Within device skew is guaranteed to be less than 20ps over supply voltage and temperature.

• Guaranteed AC performance over temperature and voltage:
  • DC-to > 3.2Gbps throughput
  • 210ps typical propagation delay (IN-to-Q)
  • <20ps within-device skew
  • <150ps rise/fall times
• Fail Safe Input - Prevents outputs from oscillating
• Ultra-low jitter design:
  • <1psRMS cycle-to-cycle jitter
  • <10psPP total jitter
  • <1psRMS random jitter
  • <10psPP deterministic jitter
• High-speed LVDS outputs
• 2.5V ±5% power supply operation
• Industrial temperature range: -40°C to +85°C
• Available in 8-pin (2mm x 2mm) MLF™ package

• Clock or data distribution
• SONET clock or data distribution
• Fibre Channel clock or data distribution
• Gigabit Ethernet clock or data distribution
