OPA2992IDGKR Integrated Circuit Chip Dual 40V 10.6MHz Low-Noise Operational Amplifiers

OPA2992IDGKR Integrated Circuit Chip Dual 40V 10.6MHz Low-Noise Operational Amplifiers

Product Description Of OPA2992IDGKR
OPA2992IDGKR is a family of high voltage (40V) general purpose operational amplifiers. These devices offer excellent DC precision and AC performance, including rail-to-rail input/output, low offset (±210µV, typical), low offset drift (±0.25µV/°C, typical) and low noise (7nV/√Hz at 1kHz, 4.4nV/√Hz at 10kHz).

Specification Of OPA2992IDGKR

Features Of OPA2992IDGKR
Low offset voltage: ±210µV
Low offset voltage drift: ±0.25µV/°C
Low noise: 7nV/√Hz at 1kHz, 4.4nV/√Hz broadband
High common-mode rejection: 115dB
Low bias current: ±10pA
Rail-to-rail input and output
MUX-friendly/comparator inputs
Amplifier operates with differential inputs up to supply rail
Amplifier can be used in open-loop or as comparator
Wide bandwidth: 10.6MHz GBW, unity-gain stable
High slew rate: 32V/µs
Low quiescent current: 2.4mA per amplifier
Wide supply: ±1.35V to ±20V, 2.7V to 40V
Robust EMIRR performance

Applications Of OPA2992IDGKR
Multiplexed data-acquisition systems
Test and measurement equipment
Motor drive: power stage and control modules
Power delivery: UPS, server, and merchantnetwork power
ADC driver and reference buffer amplifier
Programmable logic controllers
Analog input and output modules
High-side and low-side current sensing
High precision comparator
