IRL520NSTRLPBF Integrated Circuit Chip 100V HEXFET Series Single N-Channel Power MOSFET

Large Image : IRL520NSTRLPBF Integrated Circuit Chip 100V HEXFET Series Single N-Channel Power MOSFET

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	IRL520NSTRLPBF

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	TO-263-3
Delivery Time:	5-8 work days
Payment Terms:	T/T, L/C, Western Union

Contact Now

IRL520NSTRLPBF Integrated Circuit Chip 100V HEXFET Series Single N-Channel Power MOSFET

Description

Part Number:	IRL520NSTRLPBF	Vds - Drain-Source Breakdown Voltage:	100 V
Id - Continuous Drain Current:	10 A	Rds On - Drain-Source Resistance:	180 MOhms
Qg - Gate Charge:	13.3 NC	Pd - Power Dissipation:	3.8 W

IRL520NSTRLPBF Integrated Circuit Chip 100V HEXFET Series Single N-Channel Power MOSFET

Product Description Of IRL520NSTRLPBF

IRL520NSTRLPBF is a logic-level N-channel HEXFET® power MOSFET housed in a D2PAK (TO-263) surface-mount package, primarily designed for switching and driving applications involving medium to low voltages and moderate currents.

Specification Of IRL520NSTRLPBF

Series	HEXFET®
FET Type	N-Channel
Technology	MOSFET (Metal Oxide)
Drain to Source Voltage (Vdss)	100 V
Current - Continuous Drain (Id) @ 25°C	10A (Tc)
Drive Voltage (Max Rds On, Min Rds On)	4V, 10V
Rds On (Max) @ Id, Vgs	180mOhm @ 6A, 10V
Vgs(th) (Max) @ Id	2V @ 250µA
Gate Charge (Qg) (Max) @ Vgs	20 nC @ 5 V
Vgs (Max)	±16V
Input Capacitance (Ciss) (Max) @ Vds	440 pF @ 25 V
Power Dissipation (Max)	3.8W (Ta), 48W (Tc)
Operating Temperature	-55°C ~ 175°C (TJ)
Mounting Type	Surface Mount
Supplier Device Package	D2PAK
Package / Case	TO-263-3, D2PAK (2 Leads + Tab), TO-263AB

Features Of IRL520NSTRLPBF

Logic-Level Gate Drive
Advanced Process Technology
Surface Mount
175°C Operating Temperature
Fast Switching
Fully Avalanche Rated

Applications Of IRL520NSTRLPBF
Industrial SMPS
Industrial UPS
Solar string inverter
Energy storage
Charger

Other Electronic Components In Stock

Part Number	Package
ADF4368BCCZ	48-LFLGA
QM45639SR	QFN
SLG59H1405V	12-FCQFN
ADR3630ARMZ	8-MSOP
SAM9X72-I/4PB	240-TFBGA
SAM9X72T-I/4PB	240-TFBGA
SAM9X75T-I/4PB	240-TFBGA
RAA211630GNP#HA0	20-PowerVFQFN
RAA211250GNP#HA0	20-PowerVFQFN
RAA211250GSP#HA0	16-HTSSOP
RAA211450GNP#HA0	20-PowerVFQFN
RAA211835GNP#HA0	20-QFN
RAA211630GSP#HA0	16-HTSSOP
RAA211820GSP#HA0	16-TSSOP
RAA211835GSP#HA0	16-HTSSOP
RAA211820GNP#HA0	20-QFN
RAA211450GSP#HA0	16-HTSSOP
RAA2116504GNP#HA0	28-VFQFN
RAA2116514GNP#HA0	28-QFN
AD8411AWBRMZ	8-MSOP
AD8411AWBRZ	8-SOIC
LTM4702IY	49-BGA
STPM801	32-VFQFN
GAN3R2-100CBEAZ	WLCSP-8
GAN080-650EBEZ	DFN8080-8
GAN190-650EBEZ	DFN8080-8
GAN7R0-150LBEZ	FCLGA-3
GAN140-650FBEZ	DFN5060-5
GAN190-650FBEZ	DFN5060-5
GAN140-650EBEZ	DFN8080-8
