ISO7741DBQR High-Speed 100Mbps Digital Isolator with 3000Vrms Isolation and Robust EMC Quad Channel IC Chip

Large Image : ISO7741DBQR High-Speed 100Mbps Digital Isolator with 3000Vrms Isolation and Robust EMC Quad Channel IC Chip

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	ISO7741DBQR

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	SSOP-16
Delivery Time:	3-5 work days
Payment Terms:	T/T
Supply Ability:	10000 Pieces per Day

Contact Now

ISO7741DBQR High-Speed 100Mbps Digital Isolator with 3000Vrms Isolation and Robust EMC Quad Channel IC Chip

Description

Part Number:	ISO7741DBQR	Number Of Channels:	4
Inputs - Side 1/Side 2:	3/1	Voltage - Isolation:	3000Vrms
Common Mode Transient Immunity (Min):	85kV/µs	Data Rate:	100Mbps

ISO7741DBQR Integrated Circuit Chip High-Speed Robust-EMC Reinforced And Basic Quad Channel Digital Isolators

ISO7741DBQR is a high-performance, quad-channel digital isolator with 5000VRMS (DW package) and 3000VRMS (DBQ package) isolation ratings per UL 1577. This family includes devices with reinforced insulation ratings according to VDE, CSA, TUV and CQC. The ISO7741DBQR device is designed for applications that require basic insulation ratings only.

Specifications

Parameter	Value
Number of Channels	4 Channel
Polarity	Unidirectional
Data Rate	100 Mb/s
Isolation Voltage	5000 Vrms
Isolation Type	Capacitive Coupling
Supply Voltage - Max	5.5 V
Supply Voltage - Min	2.25 V
Operating Supply Current	8.6 mA, 18 mA
Propagation Delay Time	10.7 ns
Minimum Operating Temperature	-55°C
Maximum Operating Temperature	+125°C
Forward Channels	3 Channel
Maximum Fall Time	3.9 ns
Maximum Rise Time	3.9 ns
Moisture Sensitive	Yes
Power Dissipation	200 mW
Product Type	Digital Isolators
Pulse Width Distortion	0 ns
Reverse Channels	1 Channel

Key Features

100Mbps data rate
Robust isolation barrier:
- >30-year projected lifetime at 1500VRMS working voltage
- Up to 5000VRMS isolation rating
- Up to 12.8kV surge capability
- ±100kV/µs typical CMTI
Wide supply range: 2.25V to 5.5V
2.25V to 5.5V level translation
Default output high (ISO774x) and low (ISO774xF) options
Wide temperature range: -55°C to 125°C
Low power consumption, typical 1.5mA per channel at 1Mbps
Low propagation delay: 10.7ns typical (5V Supplies)
Robust electromagnetic compatibility (EMC)
System-level ESD, EFT, and surge immunity
±8kV IEC 61000-4-2 contact discharge protection across isolation barrier
Low emissions
Wide-SOIC (DW-16) and QSOP (DBQ-16) package options
Automotive version available: ISO774x-Q1
Safety-related certifications:
- DIN EN IEC 60747-17 (VDE 0884-17)
- UL 1577 component recognition program
- IEC 61010-1, IEC 62368-1, IEC 60601-1, and GB 4943.1 certifications

Applications

Industrial automation
Motor control
Power supplies
Solar inverters
Medical equipment
