LMZ21701SILR Integrated Circuit Chip 3V to 17V Input 1A Output Step-Down DC/DC Power Module with 95% Efficiency

LMZ21701SILR Integrated Circuit Chip 3V to 17V Input 1A Output Step-Down DC/DC Power Module with 95% Efficiency
LMZ21701SILR Integrated Circuit Chip 3V to 17V Input 1A Output Step-Down DC/DC Power Module with 95% Efficiency

Large Image :  LMZ21701SILR Integrated Circuit Chip 3V to 17V Input 1A Output Step-Down DC/DC Power Module with 95% Efficiency

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: LMZ21701SILR
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: Standard package
Delivery Time: 3-5 work days
Payment Terms: T/T
Supply Ability: 10000 Pieces per Day
Contact Now

LMZ21701SILR Integrated Circuit Chip 3V to 17V Input 1A Output Step-Down DC/DC Power Module with 95% Efficiency

Description
Part Number: LMZ21701SILR Number Of Outputs: 1
Voltage - Output 1: 0.9 ~ 6V Operating Temperature: -40°C ~ 125°C
Current - Output (Max): 1A Efficiency: 95%

LMZ21701SILR Integrated Circuit Chip 3V To 17V 1A Step-Down DC/DC Power Module
Product Overview

The LMZ21701SILR nano module is an easy-to-use step-down DC/DC solution capable of driving up to 1000-mA load in space-constrained applications. Only an input capacitor, an output capacitor, a soft-start capacitor, and two resistors are required for basic operation.

Specifications
Isolation: Non-Isolated
Number of Outputs: 1 Output
Input Voltage - Min: 3 V
Input Voltage - Max: 17 V
Output Voltage-Channel 1: 900 mV to 6 V
Output Current-Channel 1: 1 A
Length: 3.5 mm (0.138 in)
Width: 3.5 mm (0.138 in)
Height: 1.75 mm (0.069 in)
Maximum Operating Temperature: +125°C
Minimum Operating Temperature: -40°C
Key Features
  • Integrated Inductor
  • Miniature 3.5 mm × 3.5 mm × 1.75 mm Package
  • 35-mm² Solution Size (Single Sided)
  • -40°C to 125°C Junction Temperature Range
  • Adjustable Output Voltage
  • Integrated Compensation
  • Adjustable Soft-Start Function
  • Starts into Prebiased Loads
  • Power Good and Enable Pins
  • Seamless Transition to Power-Save Mode
  • Up to 1000 mA Output Current
  • Input Voltage Range 3 V to 17 V
  • Output Voltage Range 0.9 V to 6 V
  • Efficiency up to 95%
  • 1.5-µA Shutdown Current
  • 17-µA Quiescent Current
Applications
  • Point-of-Load Conversions from 3.3 V, 5 V, or 12 V Input Voltage
  • Space Constrained Applications
  • LDO Replacement
