HMC832LP6GE 3GHz Fractional-N Phase-Locked-Loop with Ultra Low Phase Noise Voltage Controlled Oscillator Integrated Circuit Chip

HMC832LP6GE is a 3.3 V, high performance, wide-band, Fractional-N Phase-Locked-Loop (PLL) that features an integrated Voltage Controlled Oscillator (VCO) with a fundamental frequency of 1500 MHz - 3000 MHz, and an integrated VCO Output Divider (divide by 1/2/4/6.../60/62), that enables the HMC832LP6GE to generate continuous frequencies from 25 MHz to 3000 MHz. The integrated Phase Detector (PD) and delta-sigma modulator, capable of operating at up to 100 MHz, permit wider loop-bandwidths and faster frequency tuning, with excellent spectral performance.

• RF Bandwidth: 25 - 3000 MHz
• Maximum Phase Detector Rate 100 MHz
• 3.3 V Supply
• Ultra Low Phase Noise -110 dBc/Hz in Band Typ.
• Figure of Merit (FOM) -226 dBc/Hz
• 24-bit Step Size, Resolution 3 Hz typ
• Exact Frequency Mode with 0 Hz frequency error
• Fast Frequency Hopping
• 40 Lead 6x6 mm SMT Package: 36 mm²

• Cellular Infrastructure
• Microwave Radio
• WiMax, WiFi
• Communications Test Equipment
• CATV Equipment
• DDS Replacement
• Tunable Reference Source for Spurious-Free Performance
