TIM581-2050101 2D LiDAR Sensor with 270° Horizontal Aperture Angle and Digital Output for Industrial Applications

TIM581-2050101 is a 2D LiDAR sensor designed for indoor and outdoor industrial environments, ideal for distance measurement, profile scanning, and obstacle detection applications.

• Supply voltage: 9 VDC ~ 28 VDC
• Power consumption (Typ.): 4 W
• Output current: ≤ 100 mA
• Sensing Distance: 1.97" ~ 984.25" (5 ~ 2500cm)
• Output Type: Digital
• Voltage Supply: 9V ~ 28V
• Operating Temperature: -25°C ~ 50°C

• Application: Outdoor, Indoor
• Light source: Infrared (850 nm)
• Aperture angle: Horizontal 270°
• Scanning frequency: 15 Hz
• Angular resolution: Horizontal 0.33°
• Working range: 0.05 m ~ 25 m
• Scanning range: At 10% remission factor 8 m

• AGV/AMR Navigation and Obstacle Avoidance
• Industrial Automation: Profile Detection / Dimensional Measurement
• Smart Warehousing and Logistics (Shelf / Pallet Detection)
• Security Surveillance (Perimeter Intrusion Detection)
• Construction Machinery / Vehicle Collision Avoidance

A: Yes, all products are original. New original import is our purpose.

A: We are ISO 9001:2015 Certified Company and member of ERAI.

A: Yes, we support sample orders and small orders. Sample cost varies according to your order or project requirements.

A: We use express carriers such as DHL, FedEx, UPS, TNT, and EMS. We can also use your suggested forwarder. Products are carefully packaged to ensure safety, and we are responsible for any product damage to your order.

A: We can ship stock parts within 5 working days. For non-stock items, we will confirm lead time based on your order quantity.
