Part Number:	MAX2870ETJ	Function:	Fractional, Integer-N Synthesizer/ VCO
Frequency:	23.5MHz ~ 6GHz	Number Of Circuits:	1 Circuit
Input Frequency:	10MHz ~ 200MHz	Operating Temperature:	-40°C ~ 85°C

MAX2870ETJ Integrated Circuit Chip Phase-Locked Loop TQFN-32 Voltage Controlled Oscillators

Product Overview

MAX2870ETJ is an ultra-wideband phase-locked loop (PLL) with integrated voltage controlled oscillators (VCOs) capable of operating in both integer-N and fractional-N modes. When combined with an external reference oscillator and loop filter, the MAX2870ETJ is a high-performance frequency synthesizer capable of synthesizing frequencies from 23.5MHz to 6.0GHz while maintaining superior phase noise and spurious performance.

Specifications

Product Category	Phase Locked Loops - PLL
Type	PLL + VCO
Number of Circuits	1 Circuit
Maximum Input Frequency	200 MHz
Minimum Input Frequency	10 MHz
Output Frequency Range	3 GHz to 6 GHz
Supply Voltage - Max	3.6 V
Supply Voltage - Min	3 V
Minimum Operating Temperature	-40 ℃
Maximum Operating Temperature	+85 ℃
Mounting Style	SMD/SMT
Package / Case	TQFN-32
Operating Supply Voltage	3 V to 3.6 V

Key Features

Integer and Fractional-N Modes
Manual or Automatic VCO Selection
3000MHz to 6000MHz Fundamental VCO
Output Binary Buffers/Dividers for Extended Frequency Range: 1/2/4/8/16/32/64/128 (23.5MHz to 6000MHz)
Low Phase Noise: RMS Jitter: 0.25psRMS (typ), EVM at 2.1GHz: 0.35% (typ)
High-Performance PFD: 105MHz in Integer-N Mode, 50MHz in Fractional-N Mode
Reference Frequency Up to 200MHz
Operates from +3.0V to +3.6V Supply
Dual Programmable Outputs: -4dBm to +5dBm
Analog and Digital Lock Detect Indicators
Hardware and Software Shutdown Control
Compatible with 1.8V Control Logic

Applications

Clock Generation
PMAR/LMAR/Public Safety Radio
Satellite Communications
Test and Measurement
Wireless Infrastructure
Wireless LANs/CATV
