SI8660BD-B-ISR Digital Isolator IC Chip with 5000Vrms Isolation 150Mbps Data Rate and Low Power Operation

SI8660BD-B-ISR Digital Isolator IC Chip with 5000Vrms Isolation 150Mbps Data Rate and Low Power Operation
SI8660BD-B-ISR Digital Isolator IC Chip with 5000Vrms Isolation 150Mbps Data Rate and Low Power Operation

Large Image :  SI8660BD-B-ISR Digital Isolator IC Chip with 5000Vrms Isolation 150Mbps Data Rate and Low Power Operation

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: SI8660BD-B-ISR
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: SOIC-16
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

SI8660BD-B-ISR Digital Isolator IC Chip with 5000Vrms Isolation 150Mbps Data Rate and Low Power Operation

Description
Part Number: SI8660BD-B-ISR Number Of Channels: 6
Inputs - Side 1/Side 2: 6/0 Voltage - Isolation: 5000Vrms
Common Mode Transient Immunity (Min): 35kV/µs Data Rate: 150Mbps

SI8660BD-B-ISR Integrated Circuit Chip Low Power Six-Channel Digital Isolator
Product Overview

SI8660BD-B-ISR Digital Isolators offer highly reliable, high-speed operation for demanding applications with isolation ratings up to 5kV. These digital isolators replace optocouplers in applications requiring robust operation and high levels of insulation protection, such as industrial automation and drives, motor control, and medical systems.

The SI8660BD-B-ISR provides isolation solutions for isolated AC-DC and DC-DC power supplies, solar panel microinverters, data communications systems, and hybrid electric vehicles (HEVs). These isolators deliver a data rate of 150Mbps across a temperature range of -40°C to +125ºC, with ultra-low-power operation of less than 1.6mA per channel at 1Mbps for energy-efficient system design.

Technical Specifications
Specification Value
Number of Channels 6 Channel
Polarity Unidirectional
Data Rate 150 Mb/s
Isolation Voltage 5000 Vrms
Isolation Type Capacitive Coupling
Supply Voltage - Max 5.5 V
Supply Voltage - Min 2.375 V
Propagation Delay Time 8 ns
Minimum Operating Temperature -40°C
Maximum Operating Temperature +125°C
Forward Channels 6 Channel
Maximum Fall Time 4 ns
Maximum Rise Time 4 ns
Moisture Sensitive Yes
Power Dissipation 415 mW
Pulse Width 5 ns
Pulse Width Distortion 4.5 ns
Reverse Channels 0 Channel
Shutdown Shutdown
Unit Weight 547.510 mg
Key Features
  • Up to 5000VRMS isolation
  • UL, CSA, VDE, CQC certification
  • 60-year life at rated working voltage
  • High electromagnetic immunity
  • Supply voltage 2.5 to 5.5V
  • AEC-Q100 qualification
  • Common mode transient immunity 50kV/μs
  • Independent, bidirectional SDA and SCL isolation channels
  • Open-drain outputs with 35mA sink current
  • Supports I2C clocks up to 1.7MHz
  • Unidirectional isolation channels support additional system signals
  • -40 to +125°C temperature range
Applications
  • AC induction motor
  • Battery voltage domain
  • Brushed and brushless DC motor
  • DSL integrated access device with isolated FXS
  • Electricity meters
  • Electronic lighting ballast
  • Integrated digital TV
  • Industrial automation/programmable logic controller
  • Metering aggregator
  • Motor control
  • Optical network unit
  • PLC and I/O modules
