HMC802ALP3ETR Integrated Circuit Chip 1-Bit Digital Control Attenuator with 20dB Attenuation and 0.6 dB Step Size

HMC802ALP3ETR Integrated Circuit Chip 1-Bit Digital Control Attenuator with 20dB Attenuation and 0.6 dB Step Size
HMC802ALP3ETR Integrated Circuit Chip 1-Bit Digital Control Attenuator with 20dB Attenuation and 0.6 dB Step Size

Large Image :  HMC802ALP3ETR Integrated Circuit Chip 1-Bit Digital Control Attenuator with 20dB Attenuation and 0.6 dB Step Size

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: HMC802ALP3ETR
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: QFN-16
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

HMC802ALP3ETR Integrated Circuit Chip 1-Bit Digital Control Attenuator with 20dB Attenuation and 0.6 dB Step Size

Description
Part Number: HMC802ALP3ETR Attenuation Value: 20dB
Frequency Range: 0 Hz ~ 1 GHz Number Of Bits: 1 Bit
Impedance: 50 Ohms Attenuator Step Size: 0.6 DB

HMC802ALP3ETR Integrated Circuit Chip 1-Bit Digital Positive Control Attenuator QFN-16

HMC802ALP3ETR is a broadband bidirectional 1-bit GaAs IC digital attenuator in a low cost leadless surface mount package. This single positive control line digital attenuator utilizes off chip AC ground capacitors for near DC operation, making it suitable for a wide variety of RF and IF applications. Covering DC to 10 GHz, the insertion loss is less than 3 dB typical and attenuation accuracy is excellent at ±0.6 dB typical.

HMC802ALP3ETR also features a high IIP3 of +55 dBm. One TTL/CMOS control input is used to select the attenuation state and a single Vdd bias of +5V is required.

Specifications
Product Category Attenuators
Attenuation 20 dB
Maximum Frequency 10 GHz
Impedance 50 Ohms
Number of Bits 1 bit
Number of Channels 1 Channel
Attenuator Step Size 0.6 dB
Maximum Operating Temperature +85℃
Minimum Operating Temperature -40℃
Key Features
  • ±0.6 dB typical step error
  • Low insertion loss: 3 dB
  • High IP3: +55 dBm
  • Single control line
  • TTL/CMOS compatible control
  • Single +5V supply
  • 16 Lead 3x3mm SMT package: 9mm²
Applications
  • Test equipment and sensors
  • ISM, MMDS, WLAN, WiMAX, WiBro
  • Microwave radio & VSAT
  • Cellular infrastructure
