XCZU21DR-2FFVD1156I 775MHz Field Programmable Gate Array with 16nm FinFET and Quad-core ARM Cortex-A53 Zynq UltraScale+ MPSoC

The XCZU21DR-2FFVD1156I is a high-end chip from the Zynq UltraScale+ MPSoC series manufactured by Xilinx. This series combines programmable logic, processor systems, and high-performance interconnects, making it suitable for applications requiring high computing power, real-time processing, and flexible architecture. This specific model is manufactured using advanced FinFET technology and offers an excellent performance-to-power ratio.

The XCZU21DR-2FFVD1156I incorporates a quad-core ARM Cortex-A53 processor and a dual-core ARM Cortex-R5 real-time processor, while also integrating a rich suite of hardware accelerators, graphics processing units, and video encoding/decoding modules. This makes it highly suitable for fields such as embedded vision, industrial automation, communications infrastructure, and automotive applications.

• Integrated multi-core heterogeneous processor system capable of simultaneously meeting general-purpose computing and real-time control requirements
• Supports an ARM Cortex-A53 application processor running at up to 1GHz, suitable for application development in complex operating system environments
• Provides a dedicated security module supporting AES and RSA encryption algorithms to ensure the security of data transmission and storage
• Built-in GPU and VCU (Video Codec Unit) support H.264/H.265 encoding and decoding, making it suitable for multimedia processing tasks
• The programmable logic area allows users to customize hardware acceleration functions, significantly improving system efficiency
• Support for high-speed interfaces, such as PCIe Gen3, USB 3.0, SATA and Gigabit Ethernet, provides a wide range of connectivity options
• Supports multiple operating systems, including Linux, FreeRTOS and Android, facilitating rapid development and deployment

• Embedded vision systems, such as industrial cameras, drone navigation and smart surveillance
• Automotive electronics, including Advanced Driver Assistance Systems (ADAS), infotainment systems and in-vehicle network control
• Communications equipment, such as small cells, routers and switches
• Industrial automation control, including robot controllers and motion control systems
• Medical devices, such as portable ultrasound equipment and patient monitors
• Edge computing nodes for local data processing and analysis in the Internet of Things (IoT)
