FT230XS-U Integrated Circuit Chip 12Mb/s USB Full Speed to 3MBaud UART Interface with Low Power Consumption 8mA

FT230XS-U Integrated Circuit Chip 12Mb/s USB Full Speed to 3MBaud UART Interface with Low Power Consumption 8mA
FT230XS-U Integrated Circuit Chip 12Mb/s USB Full Speed to 3MBaud UART Interface with Low Power Consumption 8mA

Large Image :  FT230XS-U Integrated Circuit Chip 12Mb/s USB Full Speed to 3MBaud UART Interface with Low Power Consumption 8mA

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: FT230XS-U
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: SSOP-16
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

FT230XS-U Integrated Circuit Chip 12Mb/s USB Full Speed to 3MBaud UART Interface with Low Power Consumption 8mA

Description
Part Number: FT230XS-U Protocol: USB
Function: Bridge, USB To UART Standards: USB 2.0
Interface: UART Voltage - Supply: 3.3V ~ 5V

FT230XS-U Integrated Circuit Chip 12Mb/s USB Full Speed To Basic UART IC In SSOP-16 Package
Product Overview
FT230XS-U USB2.0 Full Speed IC offers a compact bridge to basic UART interfaces. The device is a UART, capable of operating up to 3MBaud, with low power consumption (8mA). The FT230XS includes the complete FT-X series feature set and enables USB to be added into a system design quickly and easily over a UART interface.
Specifications
Standard USB 2.0
Speed Full Speed (FS)
Data Rate 12 Mb/s
Supply Voltage - Min 2.97 V
Supply Voltage - Max 5.5 V
Operating Supply Current 8 mA
Minimum Operating Temperature -40°C
Maximum Operating Temperature +85°C
Interface Type UART, USB
Moisture Sensitive Yes
Operating Supply Voltage 2.97 V to 5.5 V
Unit Weight 0.000776 oz
Key Features
  • I/O levels from 1.8V to 3.3V (5V Tolerant)
  • Extended temperature range of -40°C to +85°C
  • Low operating current 8mA (typical)
  • DFN package is 3.00mm x 3.00mm
  • Battery charger detection to enable higher current, faster charging
  • Extensive clocking capabilities, internal clock generation, and external clock out
  • Internal 3.3V regulator
  • Integrated crystal and Multi-Time-Programmable (MTP) memory to save board space and maximize flexibility
  • FT-X devices now have VCP driver support built into Ubuntu Linux version 11.10, kernel 3.0.0-19
Applications
  • USB to RS232/RS422/RS485 Converters
  • Upgrading Legacy Peripherals to USB
  • Cellular and Cordless Phone USB data transfer cables and interfaces
  • Interfacing MCU/PLD/FPGA based designs to USB
  • USB Audio and Low Bandwidth Video data transfer
  • PDA to USB data transfer
  • USB Smart Card Readers
  • USB Instrumentation
  • USB Industrial Control
  • USB MP3 Player Interface
  • USB FLASH Card Reader and Writers
  • Set Top Box PC - USB interface
  • USB Digital Camera Interface
  • USB Hardware Modems
  • USB Wireless Modems
  • USB Bar Code Readers
  • Dedicated Charger Port (DCP) detection enabling battery charging at higher current for faster charge times
