CY7C65642-28LTXC Low-Power USB 2.0 Hub Controller with Multiple Transaction Translator and High-Speed 480 Mb/s Data Rate

CY7C65642-28LTXC Low-Power USB 2.0 Hub Controller with Multiple Transaction Translator and High-Speed 480 Mb/s Data Rate
CY7C65642-28LTXC Low-Power USB 2.0 Hub Controller with Multiple Transaction Translator and High-Speed 480 Mb/s Data Rate

Large Image :  CY7C65642-28LTXC Low-Power USB 2.0 Hub Controller with Multiple Transaction Translator and High-Speed 480 Mb/s Data Rate

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: CY7C65642-28LTXC
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: PG-VQFN-28
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

CY7C65642-28LTXC Low-Power USB 2.0 Hub Controller with Multiple Transaction Translator and High-Speed 480 Mb/s Data Rate

Description
Part Number: CY7C65642-28LTXC Series: HX2VL TetraHub™
Interface: I2C, SPI Standards: USB 2.0
Voltage - Supply: 3.15V ~ 5.25V Operating Temperature: 0°C ~ 70°C

CY7C65642-28LTXC Integrated Circuit Chip EZ-USB™ HX2VL Low-Power Multiple Transaction Translator USB 2.0 Hub Controller

CY7C65642-28LTXC Integrated Circuit Chip EZ-USB™ HX2VL Low-Power Multiple Transaction Translator USB 2.0 Hub Controller

CY7C65642-28LTXC is a high-performance, very low-power USB 2.0 hub controller. It features integrated upstream and downstream transceivers; a USB serial interface engine (SIE); USB hub control and repeater logic; and transaction translator (TT) logic.

Specifications
Product Category USB Interface IC
Product USB Hubs
Type Hub Controller
Mounting Style SMD/SMT
Package / Case QFN-28
Standard USB 2.0
Speed High Speed (HS)
Data Rate 12 Mb/s, 480 Mb/s
Supply Voltage - Min 3.15 V
Supply Voltage - Max 5.25 V
Operating Supply Current 88.7 mA
Minimum Operating Temperature 0 ℃
Maximum Operating Temperature +70 ℃
Interface Type I2C
Operating Supply Voltage 3.15 V to 3.6 V, 4.75 V to 5.25 V
Key Features
  • High-performance, low-power USB 2.0 hub, optimized for low-cost designs with minimum bill-of-material (BOM)
  • USB 2.0 hub controller compliant with USB 2.0 specification, TID# 30000059
  • Supports up to four downstream ports with backward compatibility for FS, LS
  • Multiple transaction translator (TT), one per downstream port for maximum performance
  • Very low-power consumption supporting bus-powered and self-powered modes
  • Auto switching between bus-powered and self-powered modes
  • Single MCU with 2K ROM and 64 byte RAM
  • Highly integrated solution for reduced BOM cost with internal regulator
  • Integrated upstream pull-up resistor and pull-down resistors for all downstream ports
  • Integrated upstream/downstream termination resistors
  • Integrated port status indicator control
  • 12-MHz ±500 ppm external crystal with drive level 600 μW (integrated PLL) clock input
  • Internal power failure detection for ESD recovery
  • Downstream port management with individual and ganged mode power management
  • Overcurrent detection and two status indicators per downstream port
  • Maximum configurability through external EEPROM and I/O pin configuration
  • Supports 0°C to +70°C temperature range
Applications
  • Docking stations
  • Standalone hubs
  • Monitor hubs
  • Multi-function printers
  • Digital televisions
  • Advanced port replicators
  • Keyboard hubs
  • Gaming consoles
