40V 120A 1.8mΩ OptiMOS-T2 Automotive MOSFET Transistor Integrated Circuit Chip

40V 120A 1.8mΩ OptiMOS-T2 Automotive MOSFET Transistor Integrated Circuit Chip
40V 120A 1.8mΩ OptiMOS-T2 Automotive MOSFET Transistor Integrated Circuit Chip

Large Image :  40V 120A 1.8mΩ OptiMOS-T2 Automotive MOSFET Transistor Integrated Circuit Chip

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: IPB120N04S4-02
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: PG-TO263-3
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

40V 120A 1.8mΩ OptiMOS-T2 Automotive MOSFET Transistor Integrated Circuit Chip

Description
Part Number: IPB120N04S4-02 Drain To Source Voltage (Vdss): 40 V
Current - Continuous Drain (Id) @ 25°C: 120A (Tc) Drive Voltage (Max Rds On, Min Rds On): 10V
Vgs (Max): ±20V Operating Temperature: -55°C ~ 175°C (TJ)

IPB120N04S4-02 Integrated Circuit Chip 40V N-Channel 1.8mΩ OptiMOS™-T2 Automotive MOSFET Transistors
IPB120N04S4-02 is a 40V N-Channel 1.8mΩ OptiMOS™-T2 Automotive MOSFET Transistor in PG-TO263-3 package, designed for high-performance automotive applications.
Technical Specifications
Transistor Polarity N-Channel
Number of Channels 1 Channel
Vds - Drain-Source Breakdown Voltage 40 V
Id - Continuous Drain Current 120 A
Rds On - Drain-Source Resistance 1.58 mOhms
Vgs - Gate-Source Voltage -20 V, 20 V
Vgs th - Gate-Source Threshold Voltage 2 V
Qg - Gate Charge 134 nC
Minimum Operating Temperature -55°C
Maximum Operating Temperature +175°C
Pd - Power Dissipation 158 W
Channel Mode Enhancement
Configuration Single
Fall Time 30 ns
Product Type MOSFETs
Rise Time 16 ns
Transistor Type 1 N-Channel
Typical Turn-Off Delay Time 30 ns
Typical Turn-On Delay Time 27 ns
Unit Weight 4 g
Key Features
  • N-channel - Enhancement mode
  • Automotive AEC Q101 qualified
  • MSL1 up to 260°C peak reflow
  • 175°C operating temperature
  • Green Product (RoHS compliant)
  • 100% Avalanche tested
  • PPAP Capable Device
Performance Benefits
  • Highest current capability
  • Lowest switching and conduction losses
  • Highest thermal efficiency
  • Robust packages & superior quality
  • Optimal total gate charge
  • Smaller drivers output stages
Applications
  • Chassis control & safety
  • Electric brake booster
  • Electronic stability control
