BSC021N08NS5 80V N-Channel OptiMOS™ Power MOSFET Transistor with 226A Continuous Drain Current in SuperSO8 Package

BSC021N08NS5 80V N-Channel OptiMOS™ Power MOSFET Transistor with 226A Continuous Drain Current in SuperSO8 Package
BSC021N08NS5 80V N-Channel OptiMOS™ Power MOSFET Transistor with 226A Continuous Drain Current in SuperSO8 Package

Large Image :  BSC021N08NS5 80V N-Channel OptiMOS™ Power MOSFET Transistor with 226A Continuous Drain Current in SuperSO8 Package

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: BSC021N08NS5
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: PG-TSON-8-3
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

BSC021N08NS5 80V N-Channel OptiMOS™ Power MOSFET Transistor with 226A Continuous Drain Current in SuperSO8 Package

Description
Part Number: BSC021N08NS5 Drain To Source Voltage (Vdss): 80 V
Current - Continuous Drain (Id) @ 25°C: 226A (Tc) Drive Voltage (Max Rds On, Min Rds On): 6V, 10V
Power Dissipation (Max): 214W (Tc) 214W (Tc): ±20V

BSC021N08NS5 Integrated Circuit Chip 80V N-Channel OptiMOS™ Power MOSFET Transistors
BSC021N08NS5 Integrated Circuit Chip 80V N-Channel OptiMOS™ Power MOSFET Transistors
Product Description
BSC021N08NS5 OptiMOS™ MOSFETs in SuperSO8 package extend OptiMOS™ 3 and 5 product portfolio and enable higher power density in addition to improved robustness, responding to the need for lower system cost and increased performance. Low reverse recovery charge (Qrr) improves the system reliability by providing a significant reduction of voltage overshoot, which minimizes the need for snubber circuits, resulting in less engineering cost and effort.
Technical Specifications
Transistor Polarity: N-Channel
Number of Channels: 1 Channel
Vds - Drain-Source Breakdown Voltage: 80 V
Id - Continuous Drain Current: 100 A
Rds On - Drain-Source Resistance: 2.1 mOhms
Vgs - Gate-Source Voltage: -20 V, 20 V
Vgs th - Gate-Source Threshold Voltage: 2.2 V
Qg - Gate Charge: 117 nC
Minimum Operating Temperature: -55 °C
Maximum Operating Temperature: +175 °C
Pd - Power Dissipation: 214 W
Channel Mode: Enhancement
Configuration: Single
Fall Time: 20 ns
Forward Transconductance - Min: 70 S
Product Type: MOSFETs
Rise Time: 17 ns
Transistor Type: 1 N-Channel
Typical Turn-Off Delay Time: 44 ns
Typical Turn-On Delay Time: 13 ns
Unit Weight: 20 mg
Key Features
  • Optimized for synchronous rectification in server and desktop
  • 100% avalanche tested
  • Superior thermal resistance
  • N-channel
  • 175°C rated
  • Pb-free lead plating; RoHS compliant
  • Halogen-free according to IEC61249-2_21
Applications
  • Medium voltage IBC (48 V)
  • Edge computing
  • Telecommunications infrastructure
  • DIN rail power supply solutions
Related Product Types
Part Number Package
CY8C4148AZAS595 64-TQFP
CY8C4148AZES545 64-LQFP
CY8C4148AZSS595 64-LQFP
CY8C4149AZAS555 64-LQFP
CY8C4149AZAS558 100-LQFP
CY8C4149AZES548 100-LQFP
CY8C4149AZSS555 64-LQFP
CY8C4149LDAS563 48-QFN
CY8C4149LDES543 48-QFN
CY8C4149LDES553 48-QFN
IAUCN08S7N013 PG-TDSON-8
IMW65R020M2H PG-TO247-3
IMZA75R027M1H PG-TO247-4-3
IMZA75R090M1H PG-TO247-4-3
IPD30N10S3L34 PG-TO252-3-11
IPTC026N12NM6 PG-HDSOP-16
IQE057N10NM6CG PG-TTFN-9
IR38060MGM18TRP QFN-26
IRF7380TRPBF SOIC-8
CYT2BL8CAAQ1AZEGST 176-LQFP
DF900R12IP4DPB60 MODULE
FF900R17ME7WB11 MODULE
ASP2100MNTXG QFN-56
NCP1343FNAAABCD1R2G 10-SOP
NCP81520RMNTXG QFN-52
NCP81523MNTXG 52-VFQFN
NCP13992AKDR2G 16-SOIC
NCP13992ANDR2G 16-SOIC
NCP13992CADR2G 16-SOIC
ASP2100RMNTXG QFN-56
Frequently Asked Questions
Q: Are your products original?
A: Yes, all products are original, new original import is our purpose.
Q: Which Certificates do you have?
A: We are ISO 9001:2015 Certified Company and member of ERAI.
Q: Can you support small quantity order or sample? Is the sample free?
A: Yes, we support sample order and small order. Sample cost is different according to your order or project.
Q: How to ship my order? Is it safe?
A: We use express to ship, such as DHL, Fedex, UPS, TNT, EMS. We can also use your suggested forwarder. Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
Q: What about the lead time?
A: We can ship stock parts within 5 working days. If without stock, we will confirm lead time for you based on your order quantity.
