Automotive Eight-Channel Multi-Voltage-Level Translator Integrated Circuit Chip for Bidirectional Voltage Translation

Automotive Eight-Channel Multi-Voltage-Level Translator Integrated Circuit Chip for Bidirectional Voltage Translation
Automotive Eight-Channel Multi-Voltage-Level Translator Integrated Circuit Chip for Bidirectional Voltage Translation

Large Image :  Automotive Eight-Channel Multi-Voltage-Level Translator Integrated Circuit Chip for Bidirectional Voltage Translation

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: LSF0108QPWRQ1
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: TSSOP-20
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

Automotive Eight-Channel Multi-Voltage-Level Translator Integrated Circuit Chip for Bidirectional Voltage Translation

Description
Part Number: LSF0108QPWRQ1 Number Of Circuits: 1
Channels Per Circuit: 8 Voltage - VCCA: 0.95 V ~ 4.5 V
Voltage - VCCB: 1.8 V ~ 5.5 V Operating Temperature: -40°C ~ 125°C (TA)

LSF0108QPWRQ1 Integrated Circuit Chip Automotive Eight-Channel Bidirectional Multi-Voltage-Level Translator

LSF0108QPWRQ1 is an Automotive Eight-Channel Bidirectional Multi-Voltage-Level Translator. This device supports up to 100 MHz up translation and greater than 100 MHz down translation at ≤ 30 pF capacitive load, and up to 40 MHz up and down translation at 50 pF capacitive load.

Specifications
Parameter Value
Supply Voltage - Max 5.5 V
Supply Voltage - Min 950 mV
Series LSF0108
Propagation Delay Time 1.3 ns
Minimum Operating Temperature -40°C
Maximum Operating Temperature +125°C
Number of Channels 8 Channel
Unit Weight 76.631 kg
Features
  • AEC-Q100 qualified with the following results:
    • Device HBM ESD classification level 2000-V
    • Device CDM ESD classification level 1000-V
  • Available in wettable flank VQFN (RKS) package
  • Provides bidirectional voltage translation with no direction pin
  • Supports up to 100 MHz up translation and greater than 100 MHz down translation at ≤ 30-pF capacitive load and up to 40 MHz up or down translation at 50-pF capacitive load
  • Supports hot insertion
  • Allow bidirectional voltage level translation between:
    • 0.65 V ↔ 1.8 V, 2.5 V, 3.3 V, 5 V (RKS package only)
    • 0.95 V ↔ 1.8 V, 2.5 V, 3.3 V, 5 V
    • 1.2 V ↔ 1.8 V, 2.5 V, 3.3 V, 5 V
    • 1.8 V ↔ 2.5 V, 3.3 V, 5 V
    • 2.5 V ↔ 3.3 V, 5 V
    • 3.3 V ↔ 5 V
  • Low standby current
  • 5-V tolerance I/O port to support TTL
  • Low r on provides less signal distortion
  • High-impedance I/O pins for EN = low
  • Flow-through pin-out for easy PCB trace routing
  • Latch-up performance exceeds 100 mA per JESD 17
  • -40°C to +125°C operating temperature range
Applications
  • GPIO, MDIO, PMBus, SMBus, SDIO, UART, I2C, and other interfaces in telecom infrastructure
  • Infotainment and cluster
  • Body electronics and lighting
  • Hybrid, electric, and powertrain systems
  • Passive safety
  • ADAS
