OP297FSZ Dual Low Bias Current Precision Operational Amplifier Integrated Circuit

OP297FSZ Dual Low Bias Current Precision Operational Amplifier Integrated Circuit
OP297FSZ Dual Low Bias Current Precision Operational Amplifier Integrated Circuit

Large Image :  OP297FSZ Dual Low Bias Current Precision Operational Amplifier Integrated Circuit

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: OP297FSZ
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: SOIC-8
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

OP297FSZ Dual Low Bias Current Precision Operational Amplifier Integrated Circuit

Description
Part Number: OP297FSZ Number Of Circuits: 2
Slew Rate: 0.15V/µs Gain Bandwidth Product: 500 KHz
Current - Input Bias: 35 PA Voltage - Input Offset: 50 µV

OP297FSZ Integrated Circuit Chip Dual Low Bias Current Precision Operational Amplifier
Product Overview

The OP297FSZ is the first dual op amp to pack precision performance into the space-saving, industry standard 8-pin SO package. Its combination of precision with low power and extremely low input bias current makes the dual OP297FSZ useful in a wide variety of applications.

Specifications
Parameter Value
Number of Channels 2 Channel
GBP - Gain Bandwidth Product 500 kHz
SR - Slew Rate 150 mV/μs
Vos - Input Offset Voltage 50 μV
Ib - Input Bias Current 35 pA
Supply Voltage - Max 20 V, ±20 V
Supply Voltage - Min 2 V, ±2 V
Operating Supply Current 525 μA
Output Current per Channel 10 mA
CMRR - Common Mode Rejection Ratio 135 dB
en - Input Voltage Noise Density 20 nV/√Hz
Minimum Operating Temperature -40°C
Maximum Operating Temperature +85°C
PSRR - Power Supply Rejection Ratio 125 dB
Voltage Gain dB 130.1 dB
Unit Weight 540 mg
Key Features
  • Low offset voltage: 50 μV maximum
  • Low offset voltage drift: 0.6 μV/°C maximum
  • Very low bias current: 100 pA maximum
  • Very high open-loop gain: 2000 V/mV minimum
  • Low supply current (per amplifier): 625 μA maximum
  • Operates from ±2 V to ±20 V supplies
  • High common-mode rejection: 120 dB minimum
Applications
  • Strain gage and bridge amplifiers
  • High stability thermocouple amplifiers
  • Instrumentation amplifiers
  • Photocurrent monitors
  • High gain linearity amplifiers
  • Long-term integrators/filters
  • Sample-and-hold amplifiers
  • Peak detectors
  • Logarithmic amplifiers
  • Battery-powered systems
Other Available Products
Part Number Package
1ED3461MC12M DSO-16
2EDN7434R TSSOP-8
2ED21094S06J DSO-14
TLE9180D31QK LQFP-64
TLE75004EPD TSDSO-14
1EDI2010AS DSO-36
1EDN7512G WSON-6
TLE9183QK LQFP-64
2EDS8165H DSO-16
2EDN7534B SOT-23-6
2EDN8533F DSO-8
1EDI60H12AH DSO-8
1EDB9275F DSO-8
1EDI3020AS DSO-20
2ED21084S06J DSO-14
ISO2H823V25 VQFN-70
1EDC20I12AH DSO-8
1EDS5663H DSO-16
1EDC60I12AH DSO-8
TDA21490 QFN-39
2EDN7534G WSON-8
2EDN7534F DSO-8
2ED2104S06F DSO-8
1EDC20I12MH DSO-8
IRS2008MTRPBF 14-MLPQ
1EDN9550B SOT-23-6
1EDI3033AS DSO-20
1EDI3021AS DSO-20
TLE9180D21QK LQFP-64
1ED3461MU12M DSO-16
Frequently Asked Questions
Q: Are your products original?
A: Yes, all products are original, new original import is our purpose.
Q: Which Certificates do you have?
A: We are ISO 9001:2015 Certified Company and member of ERAI.
Q: Can you support small quantity order or sample? Is the sample free?
A: Yes, we support sample order and small order. Sample cost is different according to your order or project.
Q: How to ship my order? Is it safe?
A: We use express to ship, such as DHL, Fedex, UPS, TNT, EMS. We can also use your suggested forwarder. Products will be in good packing and ensure the safety and we are responsible to product damage to your order.
Q: What about the lead time?
A: We can ship stock parts within 5 working days. If without stock, we will confirm lead time for you based on your order quantity.
