TDA22560 Integrated Circuit Chip with 60A Output Current OptiMOS™ 6 Smart Power Stage in PG-UFLGA-34 Package

TDA22560 Integrated Circuit Chip with 60A Output Current OptiMOS™ 6 Smart Power Stage in PG-UFLGA-34 Package
TDA22560 Integrated Circuit Chip with 60A Output Current OptiMOS™ 6 Smart Power Stage in PG-UFLGA-34 Package

Large Image :  TDA22560 Integrated Circuit Chip with 60A Output Current OptiMOS™ 6 Smart Power Stage in PG-UFLGA-34 Package

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: TDA22560
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: PG-UFLGA-34
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

TDA22560 Integrated Circuit Chip with 60A Output Current OptiMOS™ 6 Smart Power Stage in PG-UFLGA-34 Package

Description
Part Number: TDA22560 Process: OptiMOS™ 6
Input Voltage: 12 V Output Current: 60 A
Output Current Range: 0 A To 60 A Package: PG-UFLGA-34

TDA22560 Integrated Circuit Chip 60A OptiMOS™ 6 Integrated Smart Power Stages PG-UFLGA-34
Product Overview

TDA22560 is an integrated smart power stage containing a low quiescent current synchronous buck gate-driver IC embedded with control and synchronous MOSFETs in a compact 4mm x 6mm package. The optimized gate driver and MOSFET combination enables higher efficiency at lower output voltages required by cutting-edge CPU, GPU, FPGA, and DDR memory designs.

Specifications
  • Process: OptiMOS™ 6
  • Input voltage: 12 V
  • Output current: 60 A
  • Output current range: 0 A to 60 A
  • Humidity sensitivity class: 3
  • Output voltage: 1.8 V
  • Package: PG-UFLGA-34
  • Switching frequency range: 200 kHz to 2000 kHz
Key Features
  • Integrated driver, Schottky diode, control MOSFET Q1 and synchronous MOSFET Q2
  • On-chip MOSFET current sensing and reporting at 5 µA/A
  • Input voltage (VIN) range of 4.25 V to 16 V
  • VCC and VDRV supply of 4.5 V to 5.5 V
  • Output voltage range from 0.225 V up to 5.5 V at VIN = 12 V
  • Output current capability of 60 A
  • Operation up to 2 MHz
  • VDRV under voltage lockout (UVLO)
  • Bootstrap under-voltage protection
  • 8mV / °C temperature analog output
  • Over temperature protection and thermal shutdown
  • Cycle-by-cycle over current protection (OCP) and flag
  • Control MOSFET short (HSS) detection and flag
  • Auto-replenishment on bootstrap capacitor
  • Compatible with 3.3 V tri-state PWM input
  • Body-Braking™ load transient support
Applications
  • High frequency, low profile DC-DC converters
  • Voltage regulators for CPUs, GPUs, FPGAs and DDR memory arrays
  • Telecom controlled and uncontrolled systems
Other Electronic Components In Stock
Part Number Package
IPP069N20NM6TO-220-3
AIMZH120R120M1TO-247-4
AIMZHN120R160M1PG-TO247-4
AIMZH120R080M1PG-TO247-4
AIMZHN120R120M1PG-TO247-4
AIMZA75R040M1PG-TO247-4
AIMZHN120R080M1PG-TO247-4
AIMZH120R060M1PG-TO247-4
AIMZA75R027M1PG-TO247-4
AIMZH120R040M1PG-TO247-4
AIMZHN120R060M1PG-TO247-4
AIMZA75R020M1PG-TO247-4
AIMZA75R016M1PG-TO247-4
AIMZHN120R040M1PG-TO247-4
AIMZA75R008M1PG-TO247-4
AIMZH120R030M1PG-TO247-4
AIMZHN120R030M1PG-TO247-4
AIMZH120R020M1PG-TO247-4
AIMZHN120R020M1PG-TO247-4
AIMZH120R010M1PG-TO247-4
AIMZHN120R010M1PG-TO247-4
AIHD04N60RTO-252-3
AIHD04N60RFTO-252-3
AIHD06N60RTO-252-3
AIHD06N60RFTO-252-3
AIHD10N60RFTO-252-3
AIHD15N60RTO-252-3
IKA15N65ET6TO-220-3
STGWA30H60DFBTO-247-3
NGTB30N120L2WGTO-247-3
