SPA15N60C3 CoolMOS™ Power Transistor with 650V Drain-Source Voltage, 15A Continuous Drain Current, and 280mOhm On-Resistance in TO-220FP-3 Package

SPA15N60C3 CoolMOS™ Power Transistor with 650V Drain-Source Voltage, 15A Continuous Drain Current, and 280mOhm On-Resistance in TO-220FP-3 Package
SPA15N60C3 CoolMOS™ Power Transistor with 650V Drain-Source Voltage, 15A Continuous Drain Current, and 280mOhm On-Resistance in TO-220FP-3 Package

Large Image :  SPA15N60C3 CoolMOS™ Power Transistor with 650V Drain-Source Voltage, 15A Continuous Drain Current, and 280mOhm On-Resistance in TO-220FP-3 Package

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: SPA15N60C3
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: PG-TO220-3
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

SPA15N60C3 CoolMOS™ Power Transistor with 650V Drain-Source Voltage, 15A Continuous Drain Current, and 280mOhm On-Resistance in TO-220FP-3 Package

Description
Part Number: SPA15N60C3 Series: CoolMOS™
Drain To Source Voltage (Vdss): 650 V Current - Continuous Drain (Id) @ 25°C: 15A (Tc)
Drive Voltage (Max Rds On, Min Rds On): 10V Rds On (Max) @ Id, Vgs: 280mOhm @ 9.4A, 10V

SPA15N60C3 Integrated Circuit Chip 650V 15A CoolMOS™ N-Channel Power Transistor PG-TO220-3
Product Description

SPA15N60C3 is an N-channel power MOSFET developed using CoolMOS™ C3 super-junction technology. Housed in a classic TO-220 FullPAK (all-plastic) package, this device offers a high voltage rating of 600 V and a low on-resistance of 280 mΩ, with a continuous current rating of 15 A.

Specifications
Product Category: MOSFETs
Technology: Si
Mounting Style: Through Hole
Package / Case: TO-220FP-3
Transistor Polarity: N-Channel
Number of Channels: 1 Channel
Vds - Drain-Source Breakdown Voltage: 600 V
Id - Continuous Drain Current: 15 A
Rds On - Drain-Source Resistance: 280 mOhms
Vgs - Gate-Source Voltage: -20 V, 20 V
Vgs th - Gate-Source Threshold Voltage: 3.9 V
Qg - Gate Charge: 63 nC
Minimum Operating Temperature: -55 ℃
Maximum Operating Temperature: +150 ℃
Pd - Power Dissipation: 34 W
Channel Mode: Enhancement
Fall Time: 5 ns
Product Type: MOSFETs
Rise Time: 5 ns
Transistor Type: 1 N-Channel
Typical Turn-Off Delay Time: 50 ns
Typical Turn-On Delay Time: 10 ns
Key Features
  • New revolutionary high voltage technology
  • Ultra low gate charge
  • Periodic avalanche rated
  • Extreme dv/dt rated
  • Ultra low effective capacitances
  • Improved transconductance
Applications
  • Switched-mode power supplies (SMPS)
  • Industrial control
  • Consumer electronics
  • Lighting and ballasts
