PSMN2R4-30YLD N-Channel MOSFET Transistor with 30V Drain to Source Voltage 2.4mΩ Rds On and 100A Continuous Drain Current

PSMN2R4-30YLD N-Channel MOSFET Transistor with 30V Drain to Source Voltage 2.4mΩ Rds On and 100A Continuous Drain Current
PSMN2R4-30YLD N-Channel MOSFET Transistor with 30V Drain to Source Voltage 2.4mΩ Rds On and 100A Continuous Drain Current

Large Image :  PSMN2R4-30YLD N-Channel MOSFET Transistor with 30V Drain to Source Voltage 2.4mΩ Rds On and 100A Continuous Drain Current

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: PSMN2R4-30YLD
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: SOT-669-5
Delivery Time: 3-5 work days
Payment Terms: T/T
Supply Ability: 10000 Pieces per Day
Contact Now

PSMN2R4-30YLD N-Channel MOSFET Transistor with 30V Drain to Source Voltage 2.4mΩ Rds On and 100A Continuous Drain Current

Description
Part Number: PSMN2R4-30YLD Drain To Source Voltage (Vdss): 30 V
Current - Continuous Drain (Id) @ 25°C: 100A (Tc) Drive Voltage (Max Rds On, Min Rds On): 4.5V, 10V
Rds On (Max) @ Id, Vgs: 2.4mOhm @ 25A, 10V Vgs(th) (Max) @ Id: 2.2V @ 1mA

PSMN2R4-30YLD Integrated Circuit Chip N-Channel 30V 2.4mΩ Logic Level MOSFET Transistors
Product Overview

PSMN2R4-30YLD Logic level gate drive N-channel enhancement mode MOSFET in LFPAK56 package. NextPowerS3 portfolio utilising unique "SchottkyPlus" technology delivers high efficiency, low spiking performance usually associated with MOSFETs with an integrated Schottky or Schottky-like diode but without problematic high leakage current. NextPowerS3 is particularly suited to high efficiency applications at high switching frequencies.

Technical Specifications
Parameter Value
Transistor Polarity N-Channel
Number of Channels 1 Channel
Vds - Drain-Source Breakdown Voltage 30 V
Id - Continuous Drain Current 100 A
Rds On - Drain-Source Resistance 2.4 mOhms
Vgs - Gate-Source Voltage -20 V, 20 V
Vgs th - Gate-Source Threshold Voltage 1.2 V
Qg - Gate Charge 31.3 nC
Minimum Operating Temperature -55 °C
Maximum Operating Temperature +175 °C
Pd - Power Dissipation 106 W
Channel Mode Enhancement
Configuration Single
Fall Time 13.9 ns
Product Type MOSFETs
Rise Time 27.5 ns
Transistor Type 1 N-Channel
Typical Turn-Off Delay Time 17.4 ns
Typical Turn-On Delay Time 16.3 ns
Part # Aliases 934067965115
Unit Weight 91.420 mg
Key Features
  • Ultra low QG, QGD and QOSS for high system efficiency, especially at higher switching frequencies
  • Superfast switching with soft-recovery; s-factor > 1
  • Low spiking and ringing for low EMI designs
  • Unique "SchottkyPlus" technology; Schottky-like performance with < 1µA leakage at 25 °C
  • Optimised for 4.5 V gate drive
  • Low parasitic inductance and resistance
  • High reliability clip bonded and solder die attach Power SO8 package; no glue, no wire bonds, qualified to 175 °C
  • Wave solderable; exposed leads for optimal visual solder inspection
Applications
  • On-board DC-to-DC solutions for server and telecommunications
  • Secondary-side synchronous rectification in telecommunication applications
  • Voltage regulator modules (VRM)
  • Point-of-Load (POL) modules
  • Power delivery for V-core, ASIC, DDR, GPU, VGA and system components
  • Brushed and brushless motor control
