174055-2 2.5mm Pitch 20 Position Wire-To-Board Automotive Connector with Dual-Locking Mechanism

174055-2 2.5mm Pitch 20 Position Wire-To-Board Automotive Connector with Dual-Locking Mechanism
174055-2 2.5mm Pitch 20 Position Wire-To-Board Automotive Connector with Dual-Locking Mechanism

Large Image :  174055-2 2.5mm Pitch 20 Position Wire-To-Board Automotive Connector with Dual-Locking Mechanism

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: 174055-2
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: 20POS
Delivery Time: 3-5 work days
Payment Terms: TT
Supply Ability: 10000 Pieces per Day
Contact Now

174055-2 2.5mm Pitch 20 Position Wire-To-Board Automotive Connector with Dual-Locking Mechanism

Description
Part Number: 174055-2 Pitch - Mating: 0.098" (2.50mm)
Number Of Positions: 20 Number Of Rows: 2
Operating Temperature: -30°C ~ 105°C Row Spacing - Mating: 0.205" (5.20mm)

174055-2 Connectors 2.5mm Pitch Wire-To-Board Automotive Connectors 20POS
Product Overview

The 174055-2 is a 2.5 mm pitch wire-to-board automotive connector from the MULTILOCK 040 series. Designed specifically for in-vehicle signal transmission, it combines a compact, high-density design with exceptional reliability, and is widely compatible with body, powertrain and infotainment systems.

Technical Specifications
Model174055-2
SeriesMULTILOCK 040 (Multi-Lock Series)
TypeWire-to-Board, horizontal (90° angled) mounting, dual-row female socket
Pitch2.5 mm (centre-to-centre)
Pins / Rows20-pin (2*10), dual-row
MountingThrough-hole soldering, compatible with 1.6 mm thick PCB
DimensionsLength 40.02mm * Width 21.72mm * Height 16.70mm
Operating Temperature-30°C to +105°C
Electrical SpecificationsRated Voltage 12VDC, Maximum Current per Contact 5A
Contact PlatingGold-plated (Au), low contact resistance, oxidation-resistant
Housing MaterialPBT (Polybutylene Terephthalate), black, flame-retardant and heat-resistant
Environmental ComplianceLead-free, RoHS compliant, Moisture Sensitivity Level (MSL) 1 (indefinite)
Key Features
  • Compact and High-Density: 20-pin dual-row layout with 2.5mm pitch, saving PCB space and suitable for miniaturised automotive ECUs
  • Dual-locking mechanism: Built-in dual-locking mechanism prevents loosening due to vibration; protects contacts during mating to avoid damage from wobbling
  • High environmental resistance: Wide temperature range of -30°C to +105°C, suitable for high and low-temperature automotive operating conditions; gold-plated contacts resist corrosion and enhance signal stability
  • Easy installation and maintenance: Horizontal through-hole soldering compatible with standard PCBs; features positioning pins for precise soldering alignment; housing includes mounting flanges for secure fixation
  • Optimised for signal transmission: Specifically designed for automotive signals, offering low crosstalk and high signal-to-noise ratio, suitable for signal chains in body control, ADAS and in-vehicle networks
Typical Applications
  • Body control systems: Door, window, seat and lighting control modules
  • Powertrain: Signal connections for engine ECUs and transmission control units
  • In-vehicle entertainment and information: Centre consoles, instrument clusters, navigation and multimedia interfaces
  • Safety systems: Signal transmission for ABS, ESP and airbag control
  • New energy vehicles: Signal connections for BMS (Battery Management System) and VCU (Vehicle Control Unit)
