MR36-SD-14-F-LI 14-pin High-Density Ribbon IDC Connector with Gold-plated Contacts for Precise Positioning

MR36-SD-14-F-LI 14-pin High-Density Ribbon IDC Connector with Gold-plated Contacts for Precise Positioning
MR36-SD-14-F-LI 14-pin High-Density Ribbon IDC Connector with Gold-plated Contacts for Precise Positioning

Large Image :  MR36-SD-14-F-LI 14-pin High-Density Ribbon IDC Connector with Gold-plated Contacts for Precise Positioning

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: MR36-SD-14-F-LI
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: Standard package
Delivery Time: 3-5 work days
Payment Terms: TT
Supply Ability: 10000 Pieces per Day
Contact Now

MR36-SD-14-F-LI 14-pin High-Density Ribbon IDC Connector with Gold-plated Contacts for Precise Positioning

Description
Part Number: MR36-SD-14-F-LI Rated Voltage: 250V
Insulation Resistance: ≥1000MΩ Operating Temperature: -55°C To +125°C

MR36-SD-14-F-LI Connectors Miniature Ribbon IDC Positioning Connector

The MR36-SD-14-F-LI is a miniature ribbon IDC positioning connector belonging to the MR36 series. Designed specifically for high-density, high-reliability board-to-board and cable connections, it integrates positioning and locking functions and is widely used in industrial control, medical equipment, telecommunications terminals and consumer electronics.

Model Breakdown
  • MR36: Series code, denoting a miniature ribbon connector with a pitch of 0.085 inches (2.16 mm) and 36-series specifications
  • SD: Socket + IDC Terminal, suitable for crimping onto flat ribbon cables
  • 14: 14-pin configuration, meeting the signal transmission requirements for medium to low channel counts
  • F: Forked Boardlocks, enhancing PCB positioning and vibration resistance
  • LI: Spring Latches Installed, providing snap-fit locking to prevent disconnection
Key Specifications
Mechanical Characteristics
  • Contact Material: Phosphor Bronze, offering excellent elasticity and resistance to repeated mating cycles
  • Contact Plating: Gold-plated over nickel (AU ON NI) on the mating surface, tin-plated on the termination surface
  • Insulation Material: UL94V-0 grade engineering plastic, flame-retardant and heat-resistant
  • Mating Cycles: ≥500 cycles, ensuring stable elasticity and reliable contact
  • Positioning Structure: Built-in positioning pins + PCB latches, ensuring precise PCB mounting
Electrical Characteristics
  • Rated current: 3A per channel
  • Rated voltage: 250V AC
  • Insulation resistance: ≥1000MΩ (500V DC)
  • Contact resistance: ≤20 mΩ
  • Operating temperature: -55°C to +125°C
Physical Characteristics
  • Pitch: 0.085 inches (2.16 mm), high-density layout
  • Number of pins: 14 pins, single-row design
  • Mounting Method: Through-hole soldering
  • Termination Type: IDC crimping, compatible with 1.27mm pitch flat ribbon cables
Key Design Advantages
  • Precise Positioning + Dual Locking: Positioning pins and fork plate lock ensure foolproof PCB alignment
  • IDC Solder-Free Efficient Assembly: Direct crimping eliminates the need for soldering
  • Highly Reliable Contact System: Phosphor bronze spring contacts with gold plating offer oxidation resistance
  • Suitable for Harsh Environments: UL94V-0 flame-retardant insulation material, wide operating temperature range
  • Compact, Miniaturised Design: 0.085-inch pitch, 14-pin single-row layout saves PCB space
Typical Applications
  • Industrial Control: Internal signal connections for PLCs, sensor modules and industrial touchscreens
  • Medical Equipment: Board-to-board connections for patient monitors, ultrasound equipment
  • Communications Terminals: Internal low-voltage signal transmission for routers and switches
  • Consumer Electronics: Internal connections for smart home devices and in-vehicle electronics
  • Test and Measurement: Signal interface connections for test instruments
Other Electronic Components In Stock
Part Number Package
MAX98400AETXTQFN-36
TGA2216SMD
SPP11N60C3TO-220
STP45N40DM2AGTO-220
1ED020I12-B2SOP-16
HE2AN-S-DC24VSMD
H3LIS331DLTRTFLGA-16
MAX996ESDSOP14
VSC8514XMK-11VQFN138
ICG-20660LLGA16
LT3748IMSMSOP16
DAC104S085CIMMMSOP10
LTC3765HMSEMSOP16
AD7476ABKSZSC70-6
AD7124-4BCPZLFCSP-32
AD7924WYRUZTSSOP-16
AD7192BRUZTSSOP-24
AD7124-8BCPZLFCSP-32
AD7982BRMZRL7MSOP-10
AD7323BRUZTSSOP-16
ADUM5230WARWZSOP-16
DAC5689IRGCRQFN64
CC115LRGPRVQFN20
NCV33272ADR2GSOP8
LM26420XSQWQFN-16
S29GL064N90FFIS40FBGA64
TLE6282GSOP20
ISO3088DWRSOP-16
