CDCS502PWR 108MHz Clock Generator with 3.3V Power Supply in TSSOP-8 Package

CDCS502PWR is a spread spectrum capable, fundamental mode crystal oscillator with selectable frequency multiplication. This advanced device features a gain-controlled fundamental mode crystal oscillator stage with built-in load capacitance of 10pF, accepting crystals from 8MHz to 32MHz with ESR up to 180Ω. The oscillator stage supports crystals with power dissipation from 50µW and above.

• Part of a family of easy-to-use clock generator devices with optional SSC
• Crystal oscillator with integrated crystal capacitors, selectable output frequency and selectable SSC
• SSC controllable via 2 external pins
• ±0%, ±0.5%, ±1%, ±2% center spread
• Frequency multiplication selectable between x1 or x4 with one external control pin
• Single 3.3V device power supply
• Wide temperature range -40°C to 85°C
• Low space consumption by 8 pin TSSOP package

• Consumer and industrial applications requiring crystal oscillator with EMI reduction through spread spectrum clocking
