HFBR-14E4Z Optical Transmitter with 160MBd Data Rate, 2.7km Transmission Distance, and Wide Operating Temperature Range -40C to +85C

HFBR-14E4Z Optical Transmitter with 160MBd Data Rate, 2.7km Transmission Distance, and Wide Operating Temperature Range -40C to +85C
HFBR-14E4Z Optical Transmitter with 160MBd Data Rate, 2.7km Transmission Distance, and Wide Operating Temperature Range -40C to +85C

Large Image :  HFBR-14E4Z Optical Transmitter with 160MBd Data Rate, 2.7km Transmission Distance, and Wide Operating Temperature Range -40C to +85C

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: HFBR-14E4Z
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: DIP
Delivery Time: 3-5 work days
Payment Terms: T/T
Supply Ability: 10000 Pieces per Day
Contact Now

HFBR-14E4Z Optical Transmitter with 160MBd Data Rate, 2.7km Transmission Distance, and Wide Operating Temperature Range -40C to +85C

Description
Part Number: HFBR-14E4Z Wavelength: 820nm
Voltage - Forward (Vf) (Typ): 1.7V Current - DC Forward (If) (Max): 100 MA
Voltage - DC Reverse (Vr) (Max): 1.8 V Capacitance: 55 PF

HFBR-14E4Z Integrated Circuit Chip Optical Transmitter

The HFBR-14E4Z fiber optic transmitter provides cost-effective, high-performance fiber optic communication links for industrial, power generation, power distribution, medical, transportation, and gaming applications.

Designed to operate with HFBR-24x2Z and HFBR-24x6Z fiber optic receivers at data rates up to 160MBd, this component is characterized with 50/125 μm, 62.5/125 μm, 100/140 μm, and 200 μm HCS® fiber optic cable.

Specifications
Product Type Transmitters
Wavelength 820 nm
Data Rate 160 MBd
Fibre Type Multimode
Rise Time 6.5 ns
Emitting Source LED
Operating Supply Voltage 5 V
Operating Temperature Range -40°C to +85°C
Application Ethernet
Transmission Distance 2.7 km
Fall Time 6.5 ns
Maximum Output Current 25 mA
Unit Weight 4.536 g
Key Features
  • Meets IEEE 802.3 Ethernet and 802.5 Token Ring Standards
  • Low Cost Transmitter
  • Data Rate up to 160MBd
  • Link Distances up to 2.7km
  • Specified with 50/125 µm, 62.5/125 µm, 100/140 µm, and 200 mm HCS Fiber
  • Wide Operating Temperature Range -40°C to +85°C
  • 820nm AlGaAs Emitters with 100% Burn-In for High Reliability
  • Unique Optical Port Design for Efficient Coupling
  • Auto-Insertable and Wave Solderable
  • No Board Mounting Hardware Required
Applications
  • Computer to Peripheral Links
  • Computer Monitor Links
  • Digital Cross Connect Links
  • Modems and Multiplexers
  • Suitable for Tempest Systems
  • Industrial Control Links
