L9369-TR Integrated Circuit Chip Automotive IC for Electric Parking Braking with ISO26262 Compliance in LQFP-64 Package

L9369-TR Integrated Circuit Chip Automotive IC for Electric Parking Braking with ISO26262 Compliance in LQFP-64 Package
L9369-TR Integrated Circuit Chip Automotive IC for Electric Parking Braking with ISO26262 Compliance in LQFP-64 Package

Large Image :  L9369-TR Integrated Circuit Chip Automotive IC for Electric Parking Braking with ISO26262 Compliance in LQFP-64 Package

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: L9369-TR
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: LQFP-64
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

L9369-TR Integrated Circuit Chip Automotive IC for Electric Parking Braking with ISO26262 Compliance in LQFP-64 Package

Description
Part Number: L9369-TR Voltage - Supply: 5.5V
Number Of Drivers: 2 Driver Package / Case: LQFP-64
Type: High-Side, Low-Side Operating Temperature: -40°C ~ 175°C (TJ)

L9369-TR Integrated Circuit Chip Automotive IC For Electric Parking Braking
Product Overview

L9369-TR is an Automotive IC specifically designed for electric parking braking applications. This integrated circuit targets system configurations in cable-puller or Motor Gear Unit (MGU) implementations, providing reliable performance for automotive safety systems.

Technical Specifications
Type High-Side, Low-Side
Mounting Style SMD/SMT
Package / Case LQFP-64
Number of Drivers 2 Driver
Number of Outputs 2 Output
Supply Voltage - Min 3.4 V
Supply Voltage - Max 40 V
Minimum Operating Temperature -40 ℃
Maximum Operating Temperature +175 ℃
Product Type Gate Drivers
Key Features
  • Functional safety concept for ISO26262 compliance
  • 4 High-side and Low-side gate pre-drivers for 8 external power NFETs
  • Overcurrent protection with programmable thresholds
  • Programmable and NFET independent thresholds for VDS monitoring
  • 10 integrated Fully differential amplifiers with low offset, very precise gain, and self-test
  • 10 separate ADC channels for digital processing of motor current and voltage measurement
  • 32-bits - 10 MHz SPI with CRC for internal setting, self-test and diagnostics
  • Full drive of external power NFETs down to 5.5 V battery input voltage
  • Monitoring on Main power supply and continuous BIST for internal regulators
  • Double Bandgap reference
  • 4 General Purpose I/O stages (GPIO)
  • Button Interface (9 configurable I/O pins) for monitoring and diagnostics in Normal and Sleep Mode
  • 2 Motor Speed Sensors (MSS) interfaces to acquire speed information feedbacks via external Hall sensors
  • System wake-up in Sleep Mode
  • Watchdog (configurable via SPI)
