MRF422 150W 35V Bipolar RF Power Transistor NPN Silicon for 30 MHz Linear Amplifier

MRF422 150W 35V Bipolar RF Power Transistor NPN Silicon for 30 MHz Linear Amplifier
MRF422 150W 35V Bipolar RF Power Transistor NPN Silicon for 30 MHz Linear Amplifier

Large Image :  MRF422 150W 35V Bipolar RF Power Transistor NPN Silicon for 30 MHz Linear Amplifier

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: MRF422
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: CASE211–11
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

MRF422 150W 35V Bipolar RF Power Transistor NPN Silicon for 30 MHz Linear Amplifier

Description
Part Number: MRF422 Transistor Type: NPN
Voltage - Collector Emitter Breakdown (Max): 35V Gain: 13dB
Power - Max: 150W Current - Collector (Ic) (Max): 20A

MRF422 Integrated Circuit Chip 35V 150W Bipolar RF Line NPN Silicon Power Transistor
Product Overview

MRF422 is a Bipolar RF Line NPN Silicon Power Transistor designed primarily for applications as a high-power linear amplifier from 2.0 to 30 MHz.

Specifications
Parameter Value
Transistor Type Bipolar Power
Technology Si
Transistor Polarity NPN
Operating Frequency 30 MHz
DC Collector/Base Gain hfe Min 15
Collector-Emitter Voltage VCEO Max 40 V
Emitter-Base Voltage VEBO 3 V
Continuous Collector Current 20 A
Minimum Operating Temperature -65℃
Maximum Operating Temperature +150℃
Configuration Single
Mounting Style Screw Mount
Package / Case 211-11
Maximum DC Collector Current 30 A
Pd - Power Dissipation 290 W
Key Features
  • Specified 28 V, 30 MHz Characteristics: Output Power = 150 W (PEP), Efficiency = 40%, Minimum Gain = 10 dB
  • Intermodulation Distortion @ 150 W (PEP) -- IMD = -30 dB (min.)
  • 100% Test for Load Mismatch at all Phase Angles with 30:1 VSWR
Applications
  • Aerospace and Defense
  • ISM
