LT3092EDD Integrated Circuit Chip 200mA 2-Terminal Programmable Current Source with 1.2V to 40V Input Range

Large Image : LT3092EDD Integrated Circuit Chip 200mA 2-Terminal Programmable Current Source with 1.2V to 40V Input Range

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	LT3092EDD

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	DFN-8
Delivery Time:	5-8 work days
Payment Terms:	T/T,L/C,Western Union

Contact Now

LT3092EDD Integrated Circuit Chip 200mA 2-Terminal Programmable Current Source with 1.2V to 40V Input Range

Description

Part Number:	LT3092EDD	Function:	Current Source
Voltage - Input:	1.2V ~ 40V	Current - Output:	200mA
Accuracy:	±1%	Operating Temperature:	-40°C ~ 125°C (TJ)

LT3092EDD Integrated Circuit Chip 200mA 2-Terminal Programmable Current Source DFN-8

Product Overview

The LT3092EDD is a programmable 2-terminal current source that requires only two resistors to set an output current between 0.5mA and 200mA. Utilizing advanced analog techniques for active output current programming, the LT3092 operates stably without input and output capacitors, offering high DC and AC impedance. This makes it ideal for intrinsically safe applications.

Specifications

Parameter	Value
Product Type	Current Monitors
Sensing Method	Low Side
Supply Voltage Range	1.2 V to 40 V
Operating Supply Current	300 uA
Accuracy	1%
Operating Temperature Range	-40 ℃ to +125 ℃
Mounting Style	SMD/SMT
Package / Case	DFN-8
Output Current	200 mA

Key Features

Programmable 2-Terminal Current Source
Maximum Output Current: 200mA
Wide Input Voltage Range: 1.2V to 40V
Input/Output Capacitors Not Required
Resistor Ratio Sets Output Current
Initial Set Pin Current Accuracy: 1%
Reverse-Voltage Protection
Reverse-Current Protection
<0.001%/V Line Regulation Typical
Current Limit and Thermal Shutdown Protection

Applications

2-Terminal Floating Current Source
GND Referred Current Source
Variable Current Source
In-Line Limiter
Intrinsic Safety Circuits
