RBN75H125S1FP4-A0 1250V 75A IGBT Transistor Integrated Circuit Chip for Power Switching Applications

RBN75H125S1FP4-A0 1250V 75A IGBT Transistor Integrated Circuit Chip for Power Switching Applications
RBN75H125S1FP4-A0 1250V 75A IGBT Transistor Integrated Circuit Chip for Power Switching Applications

Large Image :  RBN75H125S1FP4-A0 1250V 75A IGBT Transistor Integrated Circuit Chip for Power Switching Applications

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: RBN75H125S1FP4-A0
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: TO-247-3
Delivery Time: 3-5 work days
Payment Terms: T/T
Supply Ability: 10000 Pieces per Day
Contact Now

RBN75H125S1FP4-A0 1250V 75A IGBT Transistor Integrated Circuit Chip for Power Switching Applications

Description
Part Number: RBN75H125S1FP4-A0 Package: TO-247-3
Type: IGBT Transistors Continuous Collector Current Ic Max:: 300 A
Pd - Power Dissipation:: 517 W Continuous Collector Current At 25 C:: 150 A

RBN75H125S1FP4-A0 Integrated Circuit Chip 1250V 75A IGBT Transistors For Power Switching Applications

The RBN75H125S1FP4-A0 is a 1250V, 75A trench insulated-gate bipolar transistor (IGBT) that offers low collector to emitter saturation voltage, built-in fast recovery diode (FRD), and is designed for power switching applications. Available in a TO-247A package type.

Specifications
Configuration Single
Collector-Emitter Voltage VCEO Max 1.25 kV
Collector-Emitter Saturation Voltage 1.8 V
Maximum Gate Emitter Voltage -30 V, 30 V
Continuous Collector Current at 25°C 150 A
Pd - Power Dissipation 517 W
Maximum Operating Temperature +175°C
Continuous Collector Current Ic Max 300 A
Features
  • Trench gate and thin wafer technology (G8H series)
  • Built-in fast recovery diode in one package
  • Low collector to emitter saturation voltage VCE(sat) = 1.8V typ. (at IC = 75A, VGE = 15V, Ta = 25°C)
  • Quality grade: Standard
  • High-speed switching
  • Short circuit withstands time (10µs min.)
Applications
  • UPS
  • Welding
  • Photovoltaic inverters
  • Power converter systems
