LTC5507ES6 RF Power Detector Integrated Circuit Chip with 100kHz to 1GHz Frequency and Low 550µA Operating Current

LTC5507ES6 RF Power Detector Integrated Circuit Chip with 100kHz to 1GHz Frequency and Low 550µA Operating Current
LTC5507ES6 RF Power Detector Integrated Circuit Chip with 100kHz to 1GHz Frequency and Low 550µA Operating Current

Large Image :  LTC5507ES6 RF Power Detector Integrated Circuit Chip with 100kHz to 1GHz Frequency and Low 550µA Operating Current

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: LTC5507ES6
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: SOT-23-6
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

LTC5507ES6 RF Power Detector Integrated Circuit Chip with 100kHz to 1GHz Frequency and Low 550µA Operating Current

Description
Part Number: LTC5507ES6 Frequency: 100kHz ~ 1GHz
Input Range: -34dBm ~ 14dBm Voltage - Supply: 2.7V ~ 6V
Current - Supply: 550 µA Operating Temperature: -40°C ~ 85°C

LTC5507ES6 Integrated Circuit Chip 100kHz To 1GHz RF Power Detector SOT-23-6
Product Overview

LTC5507ES6 is an RF power detector designed for applications operating from 100kHz to 1000MHz. The input frequency range is determined by an external capacitor. This device combines a temperature-compensated Schottky diode peak detector and buffer amplifier in a compact 6-pin ThinSOT package.

Specifications
Type RF Power Detector
Frequency Range 100 kHz to 1 GHz
Dynamic Range 48 dB
Configuration Single
Operating Supply Voltage 2.7 V to 6 V
Maximum Diode Capacitance 33 pF
Technology Si
Maximum Operating Temperature +85 ℃
Minimum Operating Temperature -40 ℃
Mounting Style SMD/SMT
Package / Case SOT-23-6
Key Features
  • Temperature Compensated Internal Schottky Diode RF Detector
  • Wide Input Power Range: -34dBm to 14dBm
  • Ultra Wide Input Frequency Range: 100kHz to 1000MHz
  • Buffered Output
  • Wide VCC Range of 2.7V to 6V
  • Low Operating Current: 550µA
  • Low Shutdown Current: <2µA
  • Low Profile (1mm) ThinSOT™ Package
Applications
  • Wireless Transceivers
  • Wireless and Cable Infrastructure
  • RF Power Alarm
  • Envelope Detector
