LMH1228RTVT 12G UHD-SDI Dual Cable Driver IC Chip with Integrated Reclocker for Professional Video

LMH1228RTVT 12G UHD-SDI Dual Cable Driver IC Chip with Integrated Reclocker for Professional Video
LMH1228RTVT 12G UHD-SDI Dual Cable Driver IC Chip with Integrated Reclocker for Professional Video

Large Image :  LMH1228RTVT 12G UHD-SDI Dual Cable Driver IC Chip with Integrated Reclocker for Professional Video

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: LMH1228RTVT
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: WQFN-32
Delivery Time: 3-5 work days
Payment Terms: T/T
Supply Ability: 10000 Pieces per Day
Contact Now

LMH1228RTVT 12G UHD-SDI Dual Cable Driver IC Chip with Integrated Reclocker for Professional Video

Description
Part Number: LMH1228RTVT Voltage - Supply: 2.375V ~ 2.625V
Control Interface: Serial, SPI Applications: Professional Video
Standards: AES10, DVB-ASI, SMPTE Function: Driver

LMH1228RTVT Integrated Circuit Chip 12G UHD-SDI Dual Cable Driver With Integrated Reclocker
Product Description
The LMH1228RTVT device is a 12G UHD-SDI low power dual output cable driver with integrated reclocker. It supports SMPTE video rates up to 11.88 Gbps, enabling UHD video for 4K/8K applications. With a wide range clock-and-data recovery (CDR) circuit, the on-chip reclocker automatically detects and locks to all SMPTE video rates up to 11.88 Gbps. The additional reclocked 100-Ω driver output on the host-side can be used for monitoring or signal distribution purposes.
Specifications
Type 12G UHD-SDI Dual Output Cable Driver
Number of Channels 2 Channel
Operating Supply Voltage 2.5 V
Minimum Operating Temperature -40°C
Maximum Operating Temperature +85°C
Unit Weight 40 mg
Key Features
  • Supports ST-2082-1 (12G), ST-2081-1 (6G), ST-424 (3G), ST-292 (HD), and ST-259 (SD)
  • Compatible with DVB-ASI and AES10 (MADI)
  • Integrated reclocker locks to SMPTE rates of 11.88 Gbps, 5.94 Gbps, 2.97 Gbps, 1.485 Gbps or divide-by-1.001 sub-rates and 270 Mbps
  • Integrated Eye Opening Monitor (EOM)
  • Dual differential output cable drivers
  • On-chip 75-Ω termination and return loss compensation network
  • Adaptive PCB input equalizer
  • Reclocked 100-Ω loop-back output
  • Automatic slew rate control on 75-Ω outputs
  • Automatic pre-emphasis and output amplitude on 75-Ω outputs
  • Programmable de-emphasis and output amplitude on 100-Ω output
  • Polarity inversion on 75-Ω and 100-Ω outputs
  • Automatic power save in absence of input signal
  • Power Consumption: 25 mW (Typical)
  • Power-Down Control Through ENABLE Pin
  • Single 2.5-V Supply
  • Power consumption: 305 mW (typical)
  • Programmable through pins, SPI, or SMBus interface
  • -40°C to +85°C operating temperature range
  • 5-mm * 5-mm, 32-pin WQFN package
Applications
  • SMPTE compatible serial digital interface
  • UHDTV/4K/8K/HDTV/SDTV video
  • Broadcast video routers, switchers, distribution amplifiers, and monitors
  • Digital video processing and editing
