4DIR1400H Integrated Circuit Chip Quad-Channel Digital Isolator With Precise Timing And Low Power Consumption

4DIR1400H Integrated Circuit Chip Quad-Channel Digital Isolator With Precise Timing And Low Power Consumption
4DIR1400H Integrated Circuit Chip Quad-Channel Digital Isolator With Precise Timing And Low Power Consumption

Large Image :  4DIR1400H Integrated Circuit Chip Quad-Channel Digital Isolator With Precise Timing And Low Power Consumption

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: 4DIR1400H
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: PG-DSO-16
Delivery Time: 3-5 work days
Payment Terms: T/T
Supply Ability: 10000 Pieces per Day
Contact Now

4DIR1400H Integrated Circuit Chip Quad-Channel Digital Isolator With Precise Timing And Low Power Consumption

Description
Part Number: 4DIR1400H Package: PG-DSO-16
Common Mode Transient Immunity (Min): 100kV/µs Data Rate: 40Mbps
Propagation Delay TpLH / TpHL (Max): 26ns, 26ns Pulse Width Distortion (Max): 3ns

4DIR1400H Integrated Circuit Chip Quad-Channel Digital Isolators With Precise Timing And Low Power Consumption
Product Description
4DIR1400H (with 3 forward channels) provides robust reinforced isolation for high-voltage applications. Four data channels allow for simplified and high-power density designs and improve system efficiency with low power consumption. With a wide supply voltage range, active-high output enable and default low output state, it is a perfect fit for SMPS applications where reinforced isolation is required.
Specifications
Number of Channels 4 Channel
Data Rate 40 Mb/s
Isolation Voltage 5700 Vrms
Propagation Delay Time 26 ns
Minimum Operating Temperature -40°C
Maximum Operating Temperature +125°C
Forward Channels 3 Channel
Features
  • Data rates up to 40 Mbps
  • Supply voltage: 2.7 V - 6.5 V
  • VISO of 5700VRMS
  • Low current consumption 6.4 mA @ 1 Mbps
  • CMTI: 100 kV/µs (min)
  • Operating temperature: -40 to 125°C
Benefits
  • High immunity against system noise
  • Higher system efficiency
  • Reliable high default output state
  • Simplified system certification
  • Easy device replacement
  • Alternative sourcing
Applications
  • Server, telecom and Industrial Switch-Mode Power Supplies (SMPS)
  • Industrial automation systems
  • Motor drives
  • Medical equipment
  • Isolated Serial Peripheral Interface (SPI)
