ADM2486BRWZ Integrated Circuit Chip 2.5kV Signal Isolated High Speed 20Mbps Half Duplex RS-485 Transceiver

ADM2486BRWZ Integrated Circuit Chip 2.5kV Signal Isolated High Speed 20Mbps Half Duplex RS-485 Transceiver
ADM2486BRWZ Integrated Circuit Chip 2.5kV Signal Isolated High Speed 20Mbps Half Duplex RS-485 Transceiver

Large Image :  ADM2486BRWZ Integrated Circuit Chip 2.5kV Signal Isolated High Speed 20Mbps Half Duplex RS-485 Transceiver

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: ADM2486BRWZ
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: 16-SOIC
Delivery Time: 3-5 work days
Payment Terms: T/T
Supply Ability: 10000 Pieces per Day
Contact Now

ADM2486BRWZ Integrated Circuit Chip 2.5kV Signal Isolated High Speed 20Mbps Half Duplex RS-485 Transceiver

Description
Part Number: ADM2486BRWZ Voltage - Isolation: 2500Vrms
Common Mode Transient Immunity (Min): 25kV/µs Data Rate: 20Mbps
Operating Temperature: -40°C ~ 85°C Voltage - Supply: 3V, 5V

ADM2486BRWZ Integrated Circuit Chip 2.5kV Signal Isolated High Speed 20Mbps Half Duplex RS-485 Transceiver
Product Overview

ADM2486BRWZ differential bus transceiver is an integrated, galvanically isolated component designed for bidirectional data communication on multipoint bus transmission lines. It is designed for balanced transmission lines and complies with ANSI EIA/TIA-485-A and ISO 8482:1987(E).

Technical Specifications
Parameter Value
Number of Channels 3 Channel
Polarity Unidirectional
Data Rate 20 Mb/s
Isolation Voltage 2500 Vrms
Isolation Type Galvanic Isolation
Supply Voltage - Max 5.5 V
Supply Voltage - Min 2.7 V
Operating Supply Current 3 mA
Propagation Delay Time 45 ns
Minimum Operating Temperature -40°C
Maximum Operating Temperature +85°C
Key Features
  • Half-duplex, isolated RS-485 transceiver
  • PROFIBUS® compliant
  • ANSI EIA/TIA 485-A and ISO 8482:1987(E) compliant
  • 20 Mbps data rate
  • 5 V or 3 V operation (VDD1)
  • High common-mode transient immunity: >25 kV/μs
  • Isolated DE status output
  • Receiver open-circuit, fail-safe design
  • Thermal shutdown protection
  • 50 nodes on bus
  • Safety and regulatory approvals:
    • UL 1577 - VISO = 2500 V rms for 1 minute
    • IEC/CSA 62368-1
    • IEC/CSA 61010-1
    • DIN EN IEC 60747-17 (VDE 0884-17) - VIORM = 560 V peak
  • Operating temperature range: −40°C to +85°C
  • Wide body, 16-lead SOIC package
Applications
  • Isolated RS-485/RS-422 interfaces
  • PROFIBUS networks
  • Industrial field networks
  • Multipoint data transmission systems
