F3L11MR12W2M1 Automotive IGBT Module 1200V with PressFIT Contact Technology and Integrated NTC Temperature Sensor

Description

Part Number:	F3L11MR12W2M1	Series:	EasyPACK™
Drain To Source Voltage (Vdss):	1200V (1.2kV)	Current - Continuous Drain (Id) @ 25°C:	65A
Gate Charge (Qg) (Max) @ Vgs:	223nC @ 18V	Operating Temperature:	-40°C ~ 175°C (TJ)

F3L11MR12W2M1 Automotive IGBT Modules 1200V EasyPACK™ 2B CoolSiC™ MOSFET 3-Level Module

Product Description

F3L11MR12W2M1 is EasyPACK™ 2B CoolSiC™ MOSFET 3-level module in ANPC topology 1200V, 11mΩ G1 with NTC and PressFIT contact technology.

Specifications

Product Category:	MOSFET Modules
Technology:	SiC
Mounting Style:	Press Fit
Package / Case:	Module
Transistor Polarity:	N-Channel
Vds - Drain-Source Breakdown Voltage:	1.2 kV
Id - Continuous Drain Current:	100 A
Rds On - Drain-Source Resistance:	11.3 mOhms
Vgs - Gate-Source Voltage:	-10 V, +20 V
Vgs th - Gate-Source Threshold Voltage:	5.55 V
Minimum Operating Temperature:	-40℃
Maximum Operating Temperature:	+150℃
Pd - Power Dissipation:	20 mW
Configuration:	3-Phase
Fall Time:	18.5 ns
Product Type:	MOSFET Modules
Rise Time:	23.4 ns
Typical Turn-Off Delay Time:	82.9 ns
Typical Turn-On Delay Time:	26.7 ns
Vf - Forward Voltage:	4.6 V
Vr - Reverse Voltage:	1.2 kV

Key Features

Best-in-class packages with 12 mm height
Leading edge WBG material
Very low module stray inductance
Enhanced CoolSiC™ MOSFET Gen 1
Enlarged gate drive voltage window
Gate-source voltages of +20 V and -10 V
PressFIT pins
Integrated NTC temperature sensor

Applications

Battery energy storage (BESS)
EV charging
Photovoltaic
Uninterruptible power supplies (UPS)
