MLX91217LVA-ACA-000-CR 250kHz Hall Current Sensor IC with Improved Diagnostics and High Accuracy

MLX91217LVA-ACA-000-CR 250kHz Hall Current Sensor IC with Improved Diagnostics and High Accuracy
MLX91217LVA-ACA-000-CR 250kHz Hall Current Sensor IC with Improved Diagnostics and High Accuracy

Large Image :  MLX91217LVA-ACA-000-CR 250kHz Hall Current Sensor IC with Improved Diagnostics and High Accuracy

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: MLX91217LVA-ACA-000-CR
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: VA-4
Delivery Time: 3-5 work days
Payment Terms: TT
Supply Ability: 10000 Pieces per Day
Contact Now

MLX91217LVA-ACA-000-CR 250kHz Hall Current Sensor IC with Improved Diagnostics and High Accuracy

Description
Part Number: MLX91217LVA-ACA-000-CR Number Of Channels: 1
Sensitivity: 10mV/mT Frequency: DC ~ 250kHz
Linearity: ±0.2% Voltage - Supply: 4.5V ~ 5.5V

MLX91217LVA-ACA-000-CR Sensor IC 250kHz Conventional Hall Current Sensor IC With Improved Diagnostics
Product Description

MLX91217LVA-ACA-000-CR is part of the Gen 2.5 high speed current sensor IC portfolio, targeting primarily inverter/converter applications. With the Conventional Hall technology - using an external ferromagnetic core for signal concentration - currents can be measured in the range of ±50 A to ±5000 A.

Specifications
Current Rating: 12.5 mA
Sensor Type: Open Loop
Response Time: 10 μs
Accuracy: 1%
Frequency Range: 0 Hz to 250 kHz
Operating Supply Voltage: 5 V
Output Type: Analog
Height: 4.218 mm
Length: 5.38 mm
Maximum Operating Temperature: +150 °C
Minimum Operating Temperature: -40 °C
Output Voltage: 10 V
Package/Case: VA-4
Supply Voltage - Max: 5.5 V
Supply Voltage - Min: 4.5 V
Width: 1.2 mm
Features
  • Measurement range ±15 to ±450 mT
  • High accuracy
  • Fast response time < 3 μs
  • AEC-Q100 Grade 0 qualified
  • Broken wire diagnostics & clamping
  • Programmable gain, offset, filtering, clamping, …
  • Fast analog ratiometric output
  • Wideband: DC to 250kHz
  • Trim&Form options available
  • 48bit unique ID for traceability
Applications
  • Automotive:
    • Hybrid powertrain
    • Electric powertrain
  • Industrial
  • Robotics
  • Non-automotive transportation
