AD8552ARZ Integrated Circuit Chip Zero-Drift Operational Amplifier with Rail-to-Rail Input and Output and 1.5 MHz Gain Bandwidth Product

AD8552ARZ Integrated Circuit Chip Zero-Drift Operational Amplifier with Rail-to-Rail Input and Output and 1.5 MHz Gain Bandwidth Product
AD8552ARZ Integrated Circuit Chip Zero-Drift Operational Amplifier with Rail-to-Rail Input and Output and 1.5 MHz Gain Bandwidth Product

Large Image :  AD8552ARZ Integrated Circuit Chip Zero-Drift Operational Amplifier with Rail-to-Rail Input and Output and 1.5 MHz Gain Bandwidth Product

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: AD8552ARZ
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: SOIC-8
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

AD8552ARZ Integrated Circuit Chip Zero-Drift Operational Amplifier with Rail-to-Rail Input and Output and 1.5 MHz Gain Bandwidth Product

Description
Part Number: AD8552ARZ Amplifier Type: Zero-Drift
Slew Rate: 0.4V/µs Gain Bandwidth Product: 1.5 MHz
Current - Input Bias: 10 PA Current - Supply: 850µA (x2 Channels)
Highlight:

Zero-Drift Integrated Circuit Chip

,

Rail-to-Rail Input and Output Operational Amplifier

,

1.5 MHz Gain Bandwidth Product Precision Amplifier

AD8552ARZ Integrated Circuit Chip Zero-Drift Single-Supply RRIO Dual Operational Amplifiers SOIC-8
Product Description

AD8552ARZ is a dual amplifier featuring rail-to-rail input and output swings. It is guaranteed to operate from 2.7 V to 5 V with a single supply. With an offset voltage of only 1 μV and drift of 0.005 μV/°C, the AD8552ARZ is perfectly suited for applications in which error sources cannot be tolerated. Temperature, position and pressure sensors, medical equipment, and strain gage amplifiers benefit greatly from nearly zero drift over their operating temperature range.

Specifications
Product Category Precision Amplifiers
Number of Channels 2 Channel
GBP - Gain Bandwidth Product 1.5 MHz
SR - Slew Rate 400 mV/us
Vos - Input Offset Voltage 1 uV
Ib - Input Bias Current 4 nA
Supply Voltage - Max 5 V
Supply Voltage - Min 2.7 V
Operating Supply Current 1 mA
Output Current per Channel 30 mA
CMRR - Common Mode Rejection Ratio 140 dB
en - Input Voltage Noise Density 42 nV/sqrt Hz
Package / Case SOIC-8
Mounting Style SMD/SMT
Shutdown No Shutdown
Minimum Operating Temperature -40 ℃
Maximum Operating Temperature +125 ℃
PSRR - Power Supply Rejection Ratio 130 dB
Voltage Gain dB 145 dB
Key Features
  • Low offset voltage: 1 μV
  • Input offset drift: 0.005 μV/°C
  • Rail-to-rail input and output swing
  • 5 V/2.7 V single-supply operation
  • High gain, CMRR, PSRR: 130 dB
  • Ultralow input bias current: 20 pA
  • Low supply current: 700 μA/op amp
  • Overload recovery time: 50 μs
  • No external capacitors required
Applications
  • Temperature sensors
  • Pressure sensors
  • Precision current sensing
  • Strain gage amplifiers
  • Medical instrumentation
  • Thermocouple amplifiers
