MX25V1006FM1I Memory IC Chip 1Mbit 80 MHz Serial NOR Flash Memory with 2.3V ~ 3.6V Supply Voltage SOP-8

MX25V1006 is a CMOS 1Mbit Serial NOR Flash memory configured as 131,072 x 8 internally. It features a serial peripheral interface and software protocol allowing operation on a simple 3-wire bus. The three bus signals are clock input (SCLK), serial data input (SI), and serial data output (SO). Serial access to the device is enabled by CS# input.

• Supports Serial Peripheral Interface - Mode 0 and Mode 3
• 1,048,576 x 1 bit structure or 524,288 x 2 bits (Dual Output mode) Structure
• Equal Sectors with 4K byte each, or Equal Blocks with 32K/64K byte each
• Any Block can be erased individually
• Single Power Supply Operation: 2.3 to 3.6 volts for read, erase, and program operations
• Latch-up protected to 100mA from -1V to Vcc +1V
• Low Power Consumption:
  • Low active read current: 6mA(max.) at 50MHz
  • Low active programming current: 5mA(typ.)/page
  • Low active sector erase current: 5mA(typ.)
  • Low standby current: 5uA(typ.)
  • Deep power-down mode: 1uA(typ.)
