HSCHD02DR3001R Connectors HSC Series Connector For Automotive Applications
Description
HSCHD02DR3001R HSC connector system is a fully shielded interconnect system that supports data rates up to 1Gb/s and more. With 0.50mm square terminals, it allows a lighter and smaller connector design. The comprehensive shielding of these connectors provides enhanced EMI performance. It is designed for automotive applications like LvDS, camera, USB and IEEE 1394.These connectors feature coded keys and visual identification to ensure coding compliance to automotive applications.
Features
0.50mm square terminal
Coding compliant to automotive requirements
Latch-Lock mechanism
Reflow soldering capable
Right angle and vertical options
USCAR-2compliant
Benefits
Compact design
Prevents mismating
Ensures good locking through locking sound
Supports Pin-In-Paste(PIP) process
Design flexibility
Ideal for automotive applications
Applications
Infotainment System
Surround View Camera System
Advanced Driver Assistance System
