ADS1230IPWR Integrated Circuit Chip 20-Bit 80SPS 1-Channel Delta-Sigma ADC For Resistive Bridge Sensors & Weigh Scales
The ADS1230 is a precision 20-bit analog-to-digital converter (ADC) that provides a complete front-end solution for bridge sensor applications. With an onboard low-noise programmable gain amplifier (PGA), onboard oscillator, and precision 20-bit delta-sigma ADC, this IC is specifically designed for weigh scales, strain gauges, and pressure sensors.
The low-noise PGA offers gains of 64 or 128, supporting full-scale differential inputs of ±39mV or ±19.5mV respectively. The delta-sigma ADC features 20-bit effective resolution with a 3rd-order modulator and 4th-order digital filter. The device supports two data rates: 10SPS (with 50Hz and 60Hz rejection) and 80SPS, and can be clocked by internal oscillator or external clock source.
Specifications Of ADS1230
| Parameter |
Value |
| Resolution |
20 bit |
| Number of Channels |
1 Channel |
| Interface Type |
I2C, SPI |
| Sampling Rate |
80 S/s |
| Input Type |
Differential/Single-Ended |
| Architecture |
Sigma-Delta |
| Analogue Supply Voltage |
2.7 V to 5.3 V |
| Digital Supply Voltage |
2.7 V to 5.3 V |
| Operating Temperature |
-40°C to +85°C |
| Features |
50/60 Hz Rejection, Oscillator, PGA |
| INL - Integral Nonlinearity |
6.29 LSB |
| Power Consumption |
2.9 mW |
| Reference Voltage |
2.7 V to 5.3 V |
| Unit Weight |
63 mg |
Key Features Of ADS1230
- Complete front-end for bridge sensor applications
- Onboard PGA with gain of 64 or 128
- Onboard oscillator
- RMS Noise: 40nV at 10SPS (G = 128), 88nV at 80SPS (G = 128)
- 18-bit noise-free resolution
- Selectable 10SPS or 80SPS data rates
- Simultaneous 50Hz and 60Hz rejection at 10SPS
- External voltage reference up to 5V for ratiometric measurements
- Simple, pin-driven control
- Two-wire serial digital interface
- Tiny 16-pin TSSOP package
- Supply range: 2.7V to 5.3V
- Operating temperature: -40°C to +85°C
Applications Of ADS1230
- Weigh Scales
- Strain Gauges
- Pressure Sensors
- Industrial Process Control
