TPS54627DDAR Integrated Circuit Chip 4.5V To 18V 6A Synchronous Buck Converter with D-CAP2 Mode

Large Image : TPS54627DDAR Integrated Circuit Chip 4.5V To 18V 6A Synchronous Buck Converter with D-CAP2 Mode

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	TPS54627DDAR

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	HSOIC-8
Delivery Time:	3-5 work days
Payment Terms:	TT
Supply Ability:	10000 Pieces per Day

Contact Now

TPS54627DDAR Integrated Circuit Chip 4.5V To 18V 6A Synchronous Buck Converter with D-CAP2 Mode

Description

Part Number:	TPS54627DDAR	Number Of Outputs:	1
Voltage - Input (Min):	4.5V	Voltage - Input (Max):	18V
Voltage - Output (Min/Fixed):	0.765V	Current - Output:	6A
Highlight:	4.5V To 18V Integrated Circuit Chip , 6A Synchronous Buck Converter , D-CAP2 Mode TPS54627DDAR

TPS54627DDAR Integrated Circuit Chip 4.5V To 18V 6A Synchronous Buck Converter

The TPS54627 device is an adaptive on-time D-CAP2 mode synchronous-buck converter. This cost-effective solution enables system designers to complete various end-equipment power-bus regulators with low-component count and low-standby current.

Specifications Of TPS54627

Parameter	Value
Output Voltage	760 mV to 5.5 V
Output Current	6 A
Number of Outputs	1 Output
Quiescent Current	3 uA
Switching Frequency	650 kHz
Minimum Operating Temperature	-40°C
Maximum Operating Temperature	+125°C
Input Voltage	4.5 V to 18 V
Moisture Sensitive	Yes
Operating Supply Current	950 uA
Supply Voltage - Min	4.5 V
Unit Weight	70.600 mg

Key Features Of TPS54627

D-CAP2™ Mode enables fast transient response
Low-output ripple and allows ceramic output capacitor
Wide VIN input-voltage range: 4.5 V to 18 V
Output-voltage range: 0.76 V to 5.5 V
Highly efficient integrated FETs optimized for lower duty-cycle applications
36 mΩ (high-side) and 28 mΩ (low-side)
High efficiency, less than 10 µA at shutdown
High initial bandgap-reference accuracy
Adjustable soft start
Prebiased soft start
650-kHz switching frequency
Cycle-by-cycle overcurrent limit

Applications Of TPS54627

Wide range of applications for low-voltage systems
Digital-TV power supply
High-definition Blu-ray Disc™ players
Networking home terminals
Digital set-top boxes (STB)

Product Identification

TPS54627DDAR, TPS54627DDA, TPS54627DD, TPS54627D, TPS54627
