MAX33070EASA RS-485 Transceiver with 65V Fault Protection 500kbps Data Rate and Wide Operating Temperature Range

MAX33070 is fault-protected RS-485/RS-422 transceivers with high ±65V protection for overvoltage conditions on the communication bus lines, ensuring robust protection in harsh industrial environments. All devices have ±40V of common-mode range (CMR) within VCCH (+4.5V to +5.5V), exceeding the RS-485 standard of -7V to +12V, making them suitable for electrically noisy environments where different systems have shifting ground levels relative to each other.

They also incorporate a high ESD protection circuit capable of protecting against ±40kV of ESD Human Body Model (HBM) for driver outputs and receiver inputs (A and B data lines). Each device contains one driver and one receiver and operates over the +3V to +5.5V supply range, making it convenient for designers to use one part with either +3.3V or +5V supply voltages across multiple end equipment.

• Integrated Protection for Robust Communication
• Protection on Driver Outputs/Receiver Inputs (A, B Data Lines)
• ±65V Fault Protection Range on Driver Outputs/Receiver Inputs
• ±40V Common-Mode Range on Driver Outputs/Receiver Inputs
• ±40kV Human Body Model (JEDEC JS-001-2017) ESD Protection
• ±15kV Air-Gap Discharge (IEC 61000-4-2) ESD Protection
• ±10kV Contact Discharge (IEC 61000-4-2) ESD Protection
• Hot-Swap Protection
• Short-Circuit Protection
• Thermal Shutdown
• True Fail-Safe Guarantees Known Receiver Output State
• Wide Operating Temperature Range from -40°C to +125°C
• High-Performance Transceiver Enables Flexible Designs
• Compliant with RS-485 EIA/TIA-485 Standard
• 3.3 and 5.0V Supply Voltage
• 1/8 Unit Load for up to 256 Devices on the Bus

• Agriculture and Heavy Machinery
• Elevator Control
• Home and Building Automation
• Industrial Automation Equipment
• Motion Controllers
• Power Supply and UPS

Yes, all products are original, new original import is our purpose.

We are ISO 9001:2015 Certified Company and member of ERAI.

Yes, we support sample order and small order. Sample cost is different according to your order or project.

We use express to ship, such as DHL, Fedex, UPS, TNT, EMS. We can also use your suggested forwarder. Products will be in good packing and ensure the safety and we are responsible to product damage to your order.

We can ship stock parts within 5 working days. If without stock, we will confirm lead time for you based on your order quantity.
