MAX17502GATB Integrated Circuit Chip 60V 1A High-Efficiency Synchronous Step-Down DC-DC Converter

MAX17502GATB Integrated Circuit Chip 60V 1A High-Efficiency Synchronous Step-Down DC-DC Converter
MAX17502GATB Integrated Circuit Chip 60V 1A High-Efficiency Synchronous Step-Down DC-DC Converter

Large Image :  MAX17502GATB Integrated Circuit Chip 60V 1A High-Efficiency Synchronous Step-Down DC-DC Converter

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: MAX17502GATB
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: 10-TDFN
Delivery Time: 3-5 work days
Payment Terms: T/T
Supply Ability: 10000 Pieces per Day
Contact Now

MAX17502GATB Integrated Circuit Chip 60V 1A High-Efficiency Synchronous Step-Down DC-DC Converter

Description
Part Number: MAX17502GATB Voltage - Input (Min): 4.5V
Voltage - Input (Max): 60V Voltage - Output (Min/Fixed): 0.9V
Voltage - Output (Max): 55.2V Current - Output: 1A
Highlight:

60V Integrated Circuit Chip

,

1A DC-DC Converter

,

High-Efficiency MAX17502GATB

MAX17502GATB Integrated Circuit Chip 60V 1A High-Efficiency Synchronous Step-Down DC-DC Converter
Product Overview Of MAX17502

The MAX17502 is a high-efficiency, high-voltage, synchronous step-down DC-DC converter with integrated MOSFETs that operates over a 4.5V to 60V input voltage range. Available in fixed 3.3V, 5V, or adjustable output voltage (0.9V to 92%VIN), this device delivers up to 1A of current with output voltage accuracy within ±1.7% over -40°C to +125°C. The MAX17502 is offered in compact TDFN and TSSOP packages, with simulation models available.

Technical Specifications Of MAX17502
Output Voltage 12 V
Output Current 1 A
Number of Outputs 1 Output
Switching Frequency 600 kHz
Minimum Operating Temperature -40 °C
Maximum Operating Temperature +125 °C
Input Voltage 60 V
Operating Supply Current 4.75 mA
Supply Voltage - Min 4.5 V
Unit Weight 50 mg
Key Features Of MAX17502
  • Eliminates external components and reduces total cost
  • No Schottky-synchronous operation for high efficiency and reduced cost
  • Internal compensation and feedback divider for 3.3V and 5V fixed outputs
  • All-ceramic capacitors, ultra-compact layout
  • Reduces number of DC-DC regulators to stock
  • Wide 4.5V to 60V input voltage range
  • 0.9V to 92%VIN adjustable output voltage
  • Delivers up to 1A
  • 600kHz and 300kHz switching frequency options
  • Available in 10-pin, 3mm × 2mm TDFN and 14-pin, 5mm × 4.4mm TSSOP packages
  • Reduces power dissipation
  • Peak efficiency > 90%
  • Shutdown current = 0.9µA (typ)
  • Operates reliably in adverse industrial environments
  • Hiccup-mode current limit, sink current limit, and autoretry startup
  • Built-in output-voltage monitoring (open-drain active-low RESET pin)
  • Resistor-programmable EN/UVLO threshold
  • Adjustable soft-start and prebiased power-up
  • High industrial -40°C to +125°C ambient operating temperature range / -40°C to +150°C junction temperature range
Applications Of MAX17502
  • Base Station, VOIP, Telecom
  • Battery-Powered Equipment
  • General-Purpose Point-of-Load
  • Home Theater
  • HVAC and Building Control
  • Industrial Process Control
