ADA4062-4ACPZ Integrated Circuit Chip Quad Low Power JFET-Input Operational Amplifier with 1.4 MHz Gain Bandwidth and 3.3V/µs Slew Rate

ADA4062-4ACPZ Integrated Circuit Chip Quad Low Power JFET-Input Operational Amplifier with 1.4 MHz Gain Bandwidth and 3.3V/µs Slew Rate
ADA4062-4ACPZ Integrated Circuit Chip Quad Low Power JFET-Input Operational Amplifier with 1.4 MHz Gain Bandwidth and 3.3V/µs Slew Rate

Large Image :  ADA4062-4ACPZ Integrated Circuit Chip Quad Low Power JFET-Input Operational Amplifier with 1.4 MHz Gain Bandwidth and 3.3V/µs Slew Rate

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: ADA4062-4ACPZ
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: LFCSP-16
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

ADA4062-4ACPZ Integrated Circuit Chip Quad Low Power JFET-Input Operational Amplifier with 1.4 MHz Gain Bandwidth and 3.3V/µs Slew Rate

Description
Part Number: ADA4062-4ACPZ Amplifier Type: J-FET
Number Of Circuits: 4 Slew Rate: 3.3V/µs
Gain Bandwidth Product: 1.4 MHz Current - Input Bias: 2 PA
Highlight:

Quad Low Power Operational Amplifier

,

1.4 MHz Gain Bandwidth Integrated Circuit Chip

,

3.3V/µs Slew Rate JFET-Input Amplifier

ADA4062-4ACPZ Integrated Circuit Chip Quad Low Power JFET-Input Operational Amplifiers
Product Overview Of ADA4062-4

The ADA4062-4 is a quad JFET-input operational amplifier offering industry-leading performance with lower power consumption, offset voltage, drift, and ultralow bias current.

Specifications Of ADA4062-4
Parameter Value
Number of Channels 4 Channel
GBP - Gain Bandwidth Product 1.4 MHz
SR - Slew Rate 3.3 V/μs
Vos - Input Offset Voltage 2.5 mV
Ib - Input Bias Current 50 pA
Supply Voltage - Max 15 V
Supply Voltage - Min 5 V
Operating Supply Current 440 μA
Output Current per Channel 20 mA
CMRR - Common Mode Rejection Ratio 90 dB
en - Input Voltage Noise Density 36 nV/√Hz
Minimum Operating Temperature -40°C
Maximum Operating Temperature +125°C
In - Input Noise Current Density 5 fA
Maximum Dual Supply Voltage 15 V
Minimum Dual Supply Voltage 5 V
PSRR - Power Supply Rejection Ratio 74 dB
Unit Weight 20.700 mg
Key Features Of ADA4062-4
  • Low input bias current: 50 pA maximum
  • Offset voltage: 1.5 mV maximum for B grade (ADA4062-2 SOIC package), 2.5 mV maximum for A grade
  • Offset voltage drift: 4 μV/°C typical
  • Slew rate: 3.3 V/μs typical
  • CMRR: 90 dB typical
  • Low supply current: 165 μA typical
  • High input impedance
  • Unity-gain stable
Applications Of ADA4062-4
  • Power control and monitoring
  • Active filters
  • Industrial/process control
  • Body probe electronics
  • Data acquisition
  • Integrators
  • Input buffering
