BTT6200-4ESA Integrated Circuit Chip 200mΩ Quad Channel Smart High-Side Power Switch 5V ~ 36V

BTT6200-4ESA Integrated Circuit Chip 200mΩ Quad Channel Smart High-Side Power Switch 5V ~ 36V
BTT6200-4ESA Integrated Circuit Chip 200mΩ Quad Channel Smart High-Side Power Switch 5V ~ 36V

Large Image :  BTT6200-4ESA Integrated Circuit Chip 200mΩ Quad Channel Smart High-Side Power Switch 5V ~ 36V

Product Details:
Place of Origin: CN
Brand Name: Original Factory
Certification: Lead free / RoHS Compliant
Model Number: BTT6200-4ESA
Payment & Shipping Terms:
Minimum Order Quantity: 10
Price: Contact for Sample
Packaging Details: TSDSO-24
Delivery Time: 5-8 work days
Payment Terms: T/T,L/C,Western Union
Contact Now

BTT6200-4ESA Integrated Circuit Chip 200mΩ Quad Channel Smart High-Side Power Switch 5V ~ 36V

Description
Part Number: BTT6200-4ESA Number Of Outputs: 4
Ratio - Input:Output: 1:1 Voltage - Load: 5V ~ 36V
Current - Output (Max): 1A Operating Temperature: -40°C ~ 150°C (TJ)
Highlight:

Quad Channel Integrated Circuit Chip

,

200mΩ Smart High-Side Power Switch

,

5V ~ 36V BTT6200-4ESA

BTT6200-4ESA Integrated Circuit Chip 200mΩ Quad Channel Smart High-Side Power Switch
Product Overview Of BTT6200

BTT6200 is a 200 mΩ quad channel Smart High-Side Power Switch, embedded in a PG-TSDSO-24 package, providing protective functions and diagnosis.

The power transistor is built by an N-channel vertical power MOSFET with charge pump. The device is integrated in Smart6 HV technology. It is specially designed to drive lamps up to R10 W 24 V or R5 W 12 V, as well as LEDs in the harsh automotive environment.

Specifications Of BTT6200
Type High Side
Number of Outputs 4 Output
Output Current 1.5 A
Current Limit 9 A
On Resistance - Max 400 mOhms
On Time - Max 150 us
Off Time - Max 150 us
Operating Supply Voltage 5 V to 36 V
Minimum Operating Temperature -40 °C
Maximum Operating Temperature +150 °C
Supply Voltage - Max 36 V
Supply Voltage - Min 8 V
Unit Weight 111.750 mg
Key Features Of BTT6200
  • Quad channel device
  • Very low stand-by current
  • 3.3 V and 5 V compatible logic inputs
  • Electrostatic discharge protection (ESD)
  • Optimized electromagnetic compatibility
  • Logic ground independent from load ground
  • Low power DMOS leakage in OFF state
  • Green product (RoHS compliant)
Applications Of BTT6200
  • Domain controller for ADAS & autonomous driving
  • Electric vehicle drivetrain system
Product Tags

BTT6200-4ESA, BTT6200-4ES, BTT6200-4E, BTT6200-4, BTT6200
