89HPES10T4G2ZBBCG8 Ethernet IC PRECISE™ 10-Lane 4-Port Gen2 PCI Express Switch BGA-324

Large Image : 89HPES10T4G2ZBBCG8 Ethernet IC PRECISE™ 10-Lane 4-Port Gen2 PCI Express Switch BGA-324

Product Details:

Place of Origin:	CN
Brand Name:	Original Factory
Certification:	Lead free / RoHS Compliant
Model Number:	89HPES10T4G2ZBBCG8

Payment & Shipping Terms:

Minimum Order Quantity:	10
Price:	Contact for Sample
Packaging Details:	BGA-324
Delivery Time:	5-8 work days
Payment Terms:	T/T,L/C,Western Union

Contact Now

89HPES10T4G2ZBBCG8 Ethernet IC PRECISE™ 10-Lane 4-Port Gen2 PCI Express Switch BGA-324

Description

Part Number:	89HPES10T4G2ZBBCG8	Series:	PRECISE™
Interface:	PCI Express	Voltage - Supply:	3.3V
Applications:	Switch Interfacing	Package:	324-BGA
Highlight:	10-Lane Ethernet IC , 4-Port Gen2 PCI Express Switch , BGA-324 PRECISE™

89HPES10T4G2 Ethernet IC PRECISE™ 10-Lane 4-Port Gen2 PCI Express Switch BGA-324

Product Description Of 89HPES10T4G2

89HPES10T4G2 is a member of IDT's PRECISE™ family of PCI Express® switching solutions. The PES10T4G2 is a 10-lane, 4-port Gen2 peripheral chip that performs PCI Express Base switching with a feature set optimized for high performance applications such as servers, storage, and communications/networking. It provides connectivity and switching functions between a PCI Express upstream port and two downstream ports and supports switching between downstream ports.

Features Of 89HPES10T4G2

High Performance PCI Express Switch

Ten 5 Gbps Gen2 PCI Express lanes
Four switch ports
- One x4 upstream port
- Three x2 downstream ports
Low latency cut-through switch architecture
Support for Max Payload Size up to 2048 bytes
One virtual channel
Eight traffic classes
PCI Express Base Specification Revision 2.0 compliant

Flexible Architecture with Numerous Configuration Options

Automatic per port link width negotiation to x4, x2 or x1
Automatic lane reversal on all ports
Automatic polarity inversion
Ability to load device configuration from serial EEPROM

Legacy Support

PCI compatible INTx emulation
Bus locking

Highly Integrated Solution

Incorporates on-chip internal memory for packet buffering and queueing
Integrates ten 5 Gbps embedded SerDes with 8b/10b encoder/decoder (no separate transceivers needed)
- Receive equalization (RxEQ)

Reliability, Availability, and Serviceability (RAS) Features

Internal end-to-end parity protection on all TLPs ensures data integrity even in systems that do not implement end-to-end CRC (ECRC)
Supports ECRC and Advanced Error Reporting
Supports PCI Express Native Hot-Plug, Hot-Swap capable I/O
Compatible with Hot-Plug I/O expanders used on PC motherboards
Supports Hot-Swap
