OPA377AIDCKR Low-Cost Low-Noise 5.5MHz CMOS Operational Amplifier Integrated Circuit Chip

The OPA377 family of operational amplifiers are wide-bandwidth CMOS amplifiers that provide very low noise, low input bias current, and low offset voltage while operating on a low quiescent current of 0.76mA (typical).

These op amps are optimized for low-voltage, single-supply applications. The exceptional combination of AC and DC performance makes them ideal for a wide range of applications, including small signal conditioning, audio, and active filters. Additionally, these parts have a wide supply range with excellent PSRR, making them attractive for applications that run directly from batteries without regulation.

• 5.5MHz Gain bandwidth product
• 7.5nV/√Hz at 1kHz Low noise
• 1mV (max) Offset voltage
• 0.2pA Input bias current
• Rail-to-rail output
• Unity-gain stable
• EMI Input filtering
• 0.76mA/ch Quiescent current
• 2.2V to 5.5V Supply voltage

• Photodiode preamp
• Piezoelectric sensor preamp
• Sensor signal conditioning
• Audio equipment
• Active filters
